JOHN DEERE 3.152 O’RINGS ON LINER

Engine Desc: To ESN 154,765

Engine Data: O'rings on Liner Engine Info: }3 Cyl

Engine Dimensions: Bore: 3.86 in / 98 mm Pin Ø: 1.1878 in / (+/- .0001)= 30mm Block (M): T24963, T26935

Con Rod (M): T20007, R81410 Piston (M): T23481

Farm Tractors 820 1020 1030 Backhoe Loaders 300 300A

Crawler Dozers 350A 350B
Forklifts 380

Engine Series: 300

1) Engine O/H Kit TOK3481 $810.75
2) Engine I/F Kit TIK3481 $726.80 SPEC SHEET - 3.152 JOHN DEERE || Piston-Liner Kit TPLK481 $173.99 Consists of:
a) TT23481 $70.48
b) TAR70633 $33.05
c) TT23482 $12.50
d) TAR51902 $66.44
e) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TAT18031 $963.03
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE38570 $120.89
2) Head Gasket Set TRE38848 $75.17
3) Head Gasket TR98460 $32.84
4) Oil Pan Gasket TR97341 $10.88
5) Rocker Cover Gsk TR75729 $16.07
6) Timing Cover Gasket TT20273 $2.62
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TT23471 $9.57 x3
2) Bolt, Con Rod TR74194 $2.78 x6 4
3) Camshaft Kit TRE55900 $418.14 5
4) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16 3
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54985
5) Pump, Oil Tube TR113752 $11.93
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x6
6) Cam. Gear TT20070 $114.54
7) Camshaft Kit TRE55900 $418.14 5

Valve, Intake ; Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 2 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 6 With Impeller TRE62658 $75.66 6
2)
Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Injector, Pencil TAR89564 $59.20
2) Kit, Grommet TMX504 $11.61
3) Cap TAT27622 $6.18 TAR85618 $8.44
4) Washer TT29539 $0.46
5) Tube Nut TR51937 $5.77 Seal, Injector TR60746 $0.38 TR48000 $1.06

(1): Do not use with Flywheel Housing (m) T20300, T22991.
(2): Do not use with Housing (m) R54096, R70741, R74549.
(3): Conversion Kit TMX386: Available Consists of: TT31306, X1 Nipple
TR99802, X2 Hose.
(4): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410.
(5): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked
T20015, T20016, R79643, R106957, and RE522311.
(6): See the Water Pump Identification Chart to make sure these part numbers are correct. You will need the water pump casting number and will need to know if you have a stamped steel pulley or a cast iron pulley.

Page 3
JOHN DEERE 3.152 O’RINGS ON BLOCK

Engine Desc: From ESN 154,766

Engine Data: O-rings on Block Engine Dimensions: Bore: 3.86 in / 98 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm Block (M): R53240, R55100, R72967, T32339

Con Rod (M): T20007, R81410 Piston (M): AR87736, AR90550

Farm Tractors 820 830 1020 1030 Backhoe Loaders 300 300A 300B 301 301A
Crawler Dozers 350A 350B
Forklifts
380

Engine Series: 300 Engine Model: 3.152

1) Engine O/H Kit TOK3591 $758.31
2) Engine I/F Kit TIK3591 $692.72 SPEC SHEET - 3.152 JOHN DEERE Piston-Liner Kit TAR71591 $162.02 Consists of:
a) TT23481 $70.48
b) TAR70633 $33.05
c) TT23482 $12.50
d) TT32340 $60.49
e) TAR71617 $9.12
f) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 0.030
Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TAT18031 $963.03
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE38570 $120.89
2) Head Gasket Set TRE38848 $75.17
3) Head Gasket TR98460 $32.84
4) Oil Pan Gasket TR97341 $10.88
5) Rocker Cover Gsk TR75729 $16.07
6) Timing Cover Gasket TT20273 $2.62
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TT23471 $9.57 x3
2)
Bolt, Con Rod TR74194 $2.78 x6 4
3) Camshaft Kit TRE55900 $418.14 5
4) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16 3
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54985
5) Pump, Oil Tube TR113752 $11.93
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x6
6) Cam. Gear TT20070 $114.54
7) Camshaft Kit TRE55900 $418.14 5

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve
TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F 2
2) Thermostat Cover
TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 6 With Impeller TRE62658 $75.66 6 Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Injector, Pencil TAR89564 $59.20
2) Kit, Grommet TMX504 $11.61
3) Cap TAT27622 $6.18 TAR85618 $8.44
4) Washer TT29539 $0.46
5) Tube Nut TR51937 $5.77 Seal, Injector TR60746 $0.38 TR48000 $1.06

(1): Do not use with Flywheel Housing (m) T20300, T22991.
(2): Do not use with Housing (m) R54096, R70741, R74549.
(3): Conversion Kit TMX386: Available Consists of: TT31306, X1 Nipple
TR99802, X2 Hose.
(4): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410.
(5): Camshaft has a 40 mm wide front bearing journal and made for a rear
press in tachometer drive, it will replace early camshafts with narrower
front bearing journal without any issue. Replaces camshafts marked
T20015, T20016, R79643, R106957, and RE522311.
(6): See the Water Pump Identification Chart to make sure these part
numbers are correct. You will need the water pump casting number and
will need to know if you have a stamped steel pulley or a cast iron pulley.

Page 4
JOHN DEERE 3.164 SMALL PIN, O’RINGS ON LINER

Engine Desc: To ESN 179,601

Engine Data: Small Pin, O'rings on Liner Engine Info: 3 Cyl Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm Con Rod (M): T20007, R81410

Piston (M): AR78310 Farm Tractors 1520

Backhoe Loaders 302 302A

Engine Series: 300 Engine Model: 3.164

1) Engine O/H Kitt TOK3310 $834.43
2) Engine I/F Kit TIK3310 $742.85 SPEC SHEET - 3.164 Piston-Liner Kit TPLK310 $182.40 Consists of:
a) TAR78310 $85.39
b) TAR55759 $26.30
c) TT26149 $5.47
d) TAR51903 $67.96
e) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18031 $963.03
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE501578 $113.10
2) Head Gasket Set TRE38850 $43.83
3) Head Gasket TR97356 $23.74
4) Oil Pan Gasket TR97341 $10.88
5) Rocker Cover Gsk TR75729 $16.07 1) Bush, Con Rod TT23471 $9.57 x3
2) Bolt, Con Rod TR74194 $2.78 x6 3
3) Camshaft Kit TRE55900 $418.14 5
4) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16 2
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54985
5) Pump, Oil Tube TR113752 $11.93
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x6
6) Cam. Gear TT20070 $114.54
7) Camshaft Kit TRE55900 $418.14 5

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert,
Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F 1
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 6 With Impeller TRE62658 $75.66 6 1) Water Pump TAT27018 $299.99 4
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX504 $11.61
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Do not use with Housing (m) R54096, R70741, R74549.
(2): Conversion Kit TMX386: Available Consists of: TT31306, x1 Nipple
TR99802, x2 Hose.
(3): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410.
(4): (m) R48997, (m) R51039.
(5): Camshaft has a 40 mm wide front bearing journal and made for a rear
press in tachometer drive, it will replace early camshafts with narrower
front bearing journal without any issue. Replaces camshafts marked
T20015, T20016, R79643, R106957, and RE522311.
(6): See the Water Pump Identification Chart to make sure these part
numbers are correct. You will need the water pump casting number and
will need to know if you have a stamped steel pulley or a cast iron pulley.

Page 5
JOHN DEERE 3.164 SMALL PIN, O’RINGS ON BLOCK

Engine Desc: To ESN 179,601

Engine Data: Small Pin, O'rings on Block Engine Info: 3 Cyl Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm Con Rod (M): T20007, R81410

Piston (M): AR87736, AR90550 Farm Tractors 1420 1520 1530

Crawler Dozers 350B

Engine Series: 300 Engine Model: 3.164

1) Engine O/H Kit TOK3593 $787.26
2) Engine I/F Kit TIK3593 $638.45 SPEC SHEET - 3.164 Piston-Liner Kit TAR71593 $163.43 Consists of:
a) TAR78310 $85.39
b) TAR55759 $26.30
c) TT26149 $5.47
d) TR116463 $64.39
e) TAR71618 $7.95
f) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 Con Rod Bearing
TRE27348 $9.06 Std.
TRE27349 $9.06 0.010
TRE27358 $9.06 0.020
TRE27364 $9.06 0.030
Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18031 $963.03
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE501578 $113.10
2) Head Gasket Set TRE38850 $43.83
3) Head Gasket TR97356 $23.74
4) Oil Pan Gasket TR97341 $10.88
5) Rocker Cover Gsk TR75729 $16.07 1) Bush, Con Rod TT23471 $9.57 x3
2) Bolt, Con Rod TR74194 $2.78 x6
3) Camshaft Kit TRE55900 $418.14
4) Con Rod TAT18005 $87.01 3 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16 2
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54985
5) Pump, Oil Tube TR113752 $11.93
6)
Oil Pump O'Ring TR61871 $1.57 1) Lower Gear
TAT24252 $117.41
2) Lower Bushing
TT26321 $7.66
3) Upper Gear
TAT18009 $147.74
4) Upper Bushing
TT20034 $5.89
5) Cam. Follower
TT20073 $11.56 x6
6) Cam. Gear
TT20070 $114.54
7) Camshaft Kit
TRE55900 $418.14 5

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003
TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve
TR26125 $2.91
2) Rotator, Valve
TRE11410 $12.79
3) O’ring,
TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F 1
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 6 With Impeller TRE62658 $75.66 6 1) Water Pump TAT27018 $299.99 4
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector
TR60746 $0.38
TR48000 $1.06
2) Injector, Pencil
TAR89564 $59.20
3) Kit, Grommet
TMX504 $11.61
4) Cap
TAT27622 $6.18
TAR85618 $8.44
5) Washer
TT29539 $0.46
6) Tube Nut
TR51937 $5.77

(1): Do not use with Housing (m) R54096, R70741, R74549.
(2): Conversion Kit TMX386: Available Consists of: TT31306, X1 Nipple
TR99802, X2 Hose.
(3): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410.
(4): (m) R48997, (m) R51039.
(5): Camshaft has a 40 mm wide front bearing journal and made for a rear
press in tachometer drive, it will replace early camshafts with narrower
front bearing journal without any issue. Replaces camshafts marked
T20015, T20016, R79643, R106957, and RE522311.
(6): See the Water Pump Identification Chart to make sure these part
numbers are correct. You will need the water pump casting number and
will need to know if you have a stamped steel pulley or a cast iron pulley.

Page 6
JOHN DEERE 3.164 LARGE PIN, O’RINGS ON BLOCK

Engine Desc: From ESN 179,602

Engine
Data: Large Pin, O'rings on Block Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm Block (M): R55100, R72967, R72965, R80408

Con Rod (M): RE19733 (SUB FOR AT18005) Piston (M): AR77762

Farm Tractors 1530 2040 2330
Backhoe Loaders 301A 302 302A 310 Crawler Dozers 350B
350C
350D

Engine Series: 300 Engine Model: 3.164

1) Engine O/H Kit TOK3041 $781.91
2) Engine I/F Kit TIK3041 $638.45 SPEC SHEET - 3.164 Piston-Liner Kit TAR78041 $151.32 Consists of:
a) TAR77762 $77.10
b) TAR55759 $26.30
c) TR125754 $12.08
d) TR116463 $64.39
e) TAR71618 $7.95
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18031 $963.03
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T 1) O/H Gasket Set TRE501578 $113.10
2)Head Gasket Set TRE38850 $43.83
3) Head Gasket TR97356 $23.74
4) Oil Pan Gasket TR97341 $10.88
5) Rocker Cover Gsk TR75729 $16.07 1) Bush, Con Rod TR55647 $8.00 x3
2) Bolt, Con Rod TR74194 $2.78 x6 3
3) Camshaft Kit TRE55900 $418.14 5
4) Con Rod TRE16495 $92.02 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16 2
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54985
5) Pump, Oil Tube TR113752 $11.93
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x6
6) Cam. Gear TT20070 $114.54
7) Camshaft Kit TRE55900 $418.14 5

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve
TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve
TR87627 $0.48

1) Thermostat
TRE33705 $10.66
180° F 1
2) Thermostat Cover TT23620 $15.12
3) Water Temp Sensor TRE51774 $27.68 6
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer
Pump
TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair
TRE19507 $60.74 7
With Impeller TRE62658 $75.66 7 1) Water Pump
TAT27018 $299.99 4
2) Water Pump Gasket TT20242 $3.83
TT20268 $4.92

Transmission Oil Pump
TAL120106 $714.81 4 1) Seal, Injector
TR60746 $0.38
TR48000 $1.06 Pump TAL1201064 2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX504 $11.61
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer
TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Do not use with Housing (m) R54096, R70741, R74549.
(2): Conversion Kit TMX386: Available Consists of: TT31306 $10.15 x1 Nipple TR99802, x2 Hose.
(3): For Connecting Rods RE16495 and RE21076 Use Connecting Rod Bolt TR80033.
(4): (m) R48997, (m) R51039.
(5): Camshaft has a 40 mm wide front bearing journal and made for a rear
press in tachometer drive, it will replace early camshafts with narrower
front bearing journal without any issue. Replaces camshafts marked
T20015, T20016, R79643, R106957, and RE522311.
(6): Check for Proper Application.
(7): See the Water Pump Identification Chart to make sure these part
numbers are correct. You will need the water pump casting number and
will need to know if you have a stamped steel pulley or a cast iron pulley.

Page 7
JOHN DEERE 3.179D

Engine Info: 3 Cyl Engine Dimensions: Bore: 4.19 in / 106 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm Con Rod (M): R80034

Piston (M): RE24458 , RE24539, RE30250 Farm Tractors 1140 1140 1350 1550 1630 1750 1850 2040 2150 2155 2240 5000 Crawler Dozers 350D 355D
Ditch Witch JT2320 Directional Boring System

Engine Series: 300 Engine Model: 3.179D

1) Engine O/H Kit TRE47653 $771.46
2) Engine I/F Kit TIK47653 $713.89 SPEC SHEET - 3.179D Piston-Liner Kit TRE30250 $161.15 Consists of:
a) TRE19282 $107.84
b) TRE66820 $26.88
c) TR125754 $12.08
d) TR116281 $70.79
e) TAR65507 $7.24
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod
Bearing
TRE27348 $9.06 Std.
TRE27349 $9.06
0.010
TRE27358 $9.06
0.020
TRE27364 $9.06 0.030 Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TAT18031 $963.03 1
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set
TRE501578 $113.10
2) Head Gasket Set TRE38850 $43.83
3) Head Gasket TR97356 $23.74
4)

Oil Pan Gasket TR97341 $10.88
5)

Rocker Cover Gsk TR75729 $16.07 1) Bush, Con Rod CTR55647 $8.00 x3
2) Bolt, Con Rod TR80033 $3.60 x6
3) Camshaft Kit TRE55900 $418.14 8
4) Con Rod TRE16495 $92.02 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE3192 4
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54985
5) Pump, Oil Tube
TR113752 $11.93
6) Cyl Hd Cap Screw TR85363 $3.42 x14 3
Oil Pump O'Ring TR61871 $1.57 1) Lower
Gear
TAT24252 $117.41
2)
Lower
Bushing TT26321 $7.66
3) Upper
Gear
TAT18009 $147.74
4) Upper
Bushing TT20034 $5.89
5) Cam.
Follower
TT20073 $11.56
x6
6) Cam.
Gear TT20070 $114.54
7) Camshaft
Kit
TRE55900 $418.14 8
8) Camshaft TR106957 $327.73 8

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve
TR26125 $2.91
2) Rotator, Valve
TRE11410 $12.79
3) O'ring,
Valve TR8762

1) Thermostat TRE33705 $10.66
180° F 2
2) Thermostat Cover TT23620 $15.12
3) Water Temp Sensor TRE51774 $27.68 7
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51

2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74

With Impeller TRE62658 $75.66 1) Water Pump TAR97708U $249.40 5 TRE60489 $227.48 6 TAR92641 $523.16 7
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92

Transmission
Oil Pump
TAL120106 $714.81
TAL68094 $681.20 1) Seal, Injector
Pump
TR60746 $0.38 TR48000 $1.06
2) Injector,
Pencil
TAR89564 $59.20
3)
Kit,
Grommet
TMX504 $11.61 |4) Glow Plug
TRE502079 $34.28
5) Cap TAT27622 $6.18 TAR85618 $8.44
6) Washer TT29539 $0.46
7) Tube Nut TR51937 $5.77

(1): Crankshaft (m) T23516 (36 mm / 1.37” Snout.) This engine may use
TRE50979, (60 mm / 2.36” Snout) (m) R91834.
(2): Do not use with Housing (m) R54096, R70741, R74549. For Saran
Repower Engines use TRE64354.
(3): Replace all R78558 Cap Screws with Flanged Head Cap Screw
TR85363.
(4): Use on engines ESN 794193, after this ESN use TRE61767.
(5): (m) R73604.
(6): (m) R78286, (m) R70437, (m) R100812, (m) R127337, (m) R127918, (m) R55164.
(7): Check your application for proper usage.
(8): Camshaft has a 40 mm wide front bearing journal and made for a rear
press in tachometer drive, it will replace early camshafts with narrower
front bearing journal without any issue. Replaces camshafts marked
T20015, T20016, R79643, R106957, and RE522311.

Page 8
JOHN DEERE 3029D LITER DESIGNATED

Engine Desc: Liter Designated
Engine Info: 3 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm Con Rod (M): R51727, R80034

Piston (M): RE30250 Farm Tractors 5200 5300 5400 Skid Steers 240 240 Series

Engine Series: 300 Engine Model: 3029D

1)Engine O/H Kit TRE47653 $771.46
2) Engine I/F Kit TIK47653 $713.89 SPEC SHEET - 3029D Piston-Liner Kit TRE30250 $161.15 Consists of:
a) TRE19282 $107.84
b) TRE66820 $26.88
c) TR125754 $12.08
d) TR116281 $70.79
e) TAR65507 $7.24
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TRE521348 $1,330.74 5
4) Crankshaft, Gear TT20094 $75.08 3 $67.03
5) Ring Gear TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501578 $113.10
2)Head Gasket Set TRE38850 $43.83
3) Head Gasket TR97356 $23.74
4) Oil Pan Gasket TR97341 $10.88
5) Rocker Cover Gsk TR75729 $16.07 2 $16.07 TR106796 $10.02 1 1) Bush, Con Rod TR55647 $8.00 x3
2) Bolt, Con Rod TR80033 $3.60 x6
3) Camshaft Kit TRE55900 $418.14 9
4) Con Rod TRE16495 $92.02 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE61767 $211.92
3) Pump, Oil Tube TR113752 $11.93
4) Cyl Hd Cap Screw TR85363 $3.42 x14 4
5) Oil Pump O'Ring TR61871 $1.57 1)
Lower Gear TAT24252 $117.41 3
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74 3
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x6
6) Cam. Gear TT20070 $114.54 3
7) Camshaft Kit TRE55900 $418.14 9
8) Camshaft TR106957 $327.73 9

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 O/S TR98335 $30.57 O/S
2) Insert, Valve Ex TR51734 $12.96 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

1) Thermostat TRE64354 $10.66
180° F
2) Thermostat Cover
TT23620 $15.12
3) Water Temp Sensor
TRE51774 $27.68 8
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31
3) Fuel Filter Base with Prime TRE67225 $159.99 Water Pump Repair Kit Without Impeller TRE19507 $60.74 10
With Impeller TRE62658 $75.66 10 1) Water Pump TAR97708U $249.40 6 TRE60489 $227.48 7
TAR92641 $523.16 8
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE36936 $59.20
3) Kit, Grommet TMX504 $11.61

(1): Not included in Gasket Set. Used in Saran Engines (Order Separately).
(2): Reusable.
(3): Helicoidal Gears.
(4): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.
(5): Kit contains TT20094 $75.08 helical gear to convert to a TRE50979,
Crankshaft.
(6): (m) R73604.
(7): m) R100812, (m) R127337, (m) R127918, (m) R55164.
(8): Check your application for proper usage.
(9): Camshaft has a 40 mm wide front bearing journal and made for a rear
press in tachometer drive, it will replace early camshafts with narrower
front bearing journal without any issue. Replaces camshafts marked
T20015, T20016, R79643, R106957, and RE522311.
(10): See the Water Pump Identification Chart to make sure these part
numbers are correct. You will need the water pump casting number and
will need to know if you have a stamped steel pulley or a cast iron pulley.

Page 9
JOHN DEERE 3.179T

Engine Info: 3 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .0002) = 41mm Con Rod (M): R80032

Piston (M): RE22678 Farm Tractors 2355NCS 2355NTSS Ditch Witch JT2321 Directional Boring System

Engine Series: 300 Engine Model: 3.179T

1) Engine O/H Kit TOK3115 $781.72
2) Engine I/F Kit TIK3115 $679.31 SPEC SHEET - 3.179T, 3029T Piston-Liner Kit TRE33115 $161.15 Consists of:
a) TRE19278 $107.84
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR116281 $70.79
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TAT18031 $963.03 3
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501578 $113.10
2) Head Gasket Set TRE38850 $43.83
3) Head Gasket TR97356 $23.74
4) Oil Pan Gasket TR97341 $10.88
5) Rocker Cover Gsk TR75729 $16.07 1) Bush, Con Rod TR57451 $11.38 x3
2) Bolt, Con Rod TR80033 $3.60 x6
3) Con Rod TRE58347 $103.07
4) Kit, Piston Pin TRE63913 $27.07 x3 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16 4
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54985
5) Pump, Oil Tube TR113752 $11.93
6) Cyl Hd Cap Screw TR85363 $3.42 x14 2
7) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x6
6) Cam. Gear TT20070 $114.54
7) Camshaft Kit TRE55900 $418.14 8
8) Camshaft TR106957 $327.73 8

Valve, Intake TR83071 $15.56 Std. TR89223 $19.73 0.003 TR89224 $17.44 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F 1
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 9

With Impeller TRE62658 $75.66 9 1) Water Pump TAR97708U $249.40 5
TRE60489 $227.48 6 TAR92641 $523.16 7
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE37503 $59.20
3) KIT, GROMMET TMX504 $11.61
4) Glow Plug TRE502079 $34.28

(1): Do not use with Housing (m) R54096, R70741, R74549. For Saran
Repower Engines use TRE64354.
(2): Replace all R78558 Cap Screws with Flanged Head Cap Screw
TR85363.
(3): Crankshaft (m) T23516 (36 mm / 1.37” Snout.) This engine may use
TRE50979, (60 mm / 2.36” Snout) (m) R91834.
(4): Use on engines ESN 794193, after this ESN use TRE61767.
(5): (m) R73604.
(6): (m) R100812, (m) R127337, (m) R127918, (m) R55164.
(7): Check your application for proper usage.
(8): Camshaft has a 40 mm wide front bearing journal and made for a rear
press in tachometer drive, it will replace early camshafts with narrower
front bearing journal without any issue. Replaces camshafts marked
T20015, T20016, R79643, R106957, and RE522311.
(9): See the Water Pump Identification Chart to make sure these part
numbers are correct. You will need the water pump casting number and
will need to know if you have a stamped steel pulley or a cast iron pulley.

Page 10
JOHN DEERE 3029T LITER DESIGNATED

Engine Desc: Liter Designated

Engine Info: 3 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .000
2)= 41mm Con Rod (M): R80032, R58979, R113612

Piston (M): RE48368 Farm Tractors 5500 Skid

Steers 250 250 Series II 260 260 Series II 8875 Engine Model 3029DLV51 3029DLV52 3029DLV53 3029DLV55 3029DLV56 3029DLV57 3029TLV52
Ditch Witch JT2321 Directional Boring System

Engine Series: 300 Engine Model: 3029T

1) Engine O/H Kit TOK3115 $781.72
2) Engine I/F Kit TIK3115 $679.31 SPEC SHEET - 3.179T, 3029T Piston-Liner Kit TRE33115 $161.15 Consists of:
a) TRE19278 $107.84
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR116281 $70.79
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TRE521348 $1,330.74 5
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501578 $113.10
2)Head Gasket Set TRE38850 $43.83
3) Head Gasket TR97356 $23.74
4) Oil Pan Gasket TR97341 $10.88
5) Rocker Cover Gsk TR75729 $16.07 2 TR106796 $10.02 1 1) Bush, Con Rod TR57451 $11.38 x3
2) Bolt, Con Rod TR80033 $3.60 x6
3) Con Rod TRE58347 $103.07
4) Kit, Piston Pin TRE63913 $27.07 x3 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE61767 $211.92
3) Pump, Oil Tube TR113752 $11.93
4) Cyl Hd Cap Screw TR85363 $3.42 x14 4
5) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41 3
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74 3
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x6
6) Cam. Gear TT20070 $114.54 3
7) Camshaft Kit TRE55900 $418.14 9
8) Camshaft TR106957 $327.73 9

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.01 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 O/S TR98335 $30.57 O/S
2)
Insert, Valve Ex TR51734 $12.96 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

1) Thermostat
TRE64354 $10.66 180¢X F
2) Thermostat Cover
TT23620 $15.12
3) Water Temp Sensor
TRE51774 $27.68 8
4) Thermostat Cover Gsk
TT20215 $0.84 1)
Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31
3) Fuel Filter Base with Prime TRE67225 $159.99 Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 1) Water Pump TAR97708U $249.40 6 TRE60489 $227.48 7 TAR92641 $523.16 8
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE38087 $77.63 8
TRE50833 $104.56 8
3) Inj Grommet Kit8 TMX504 $11.61

(1): Not included in Gasket Set. Used in Saran Engines (Order separately). (2): Reusable.
(3): Helicoidal Gears.
(4): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.
(5): Kit contains TT20094 $75.08 helical gear to convert to a TRE50979,
Crankshaft.
(6): (m) R73604.
(7): (m) R100812, (m) R127337, (m) R127918, (m) R55164.
(8): Check your application for proper usage.
(9): Camshaft has a 40 mm wide front bearing journal and made for a rear
press in tachometer drive, it will replace early camshafts with narrower
front bearing journal without any issue. Replaces

Page 11
JOHN DEERE 4.202 O’RINGS ON LINER

Engine Desc: To 158,257

Engine Data: O'rings on Liner Engine Dimensions: Bore: 3.86 in / 98 mm (2) Pin Ø: 1.1878 in (+/- .0001) = 30mm

Block (M): T23406, T24961, T26933 Con Rod (M): RE19733 (SUB FOR AT18005)

Piston (M): T23481

Farm Tractors 2020 2510 Backhoe Loaders 400

Crawler Dozers 450 Skidders 440

Forklifts 480

Engine Series: 300 Engine Model: 4.202

1) Engine O/H Kit TOK4481 $1,048.57
2) Engine I/F Kit TIK4481 $965.60 SPEC SHEET - 4.202 Piston-Liner Kit TPLK481 $173.99 Consists of:
a) TT23481 $70.48
b) TAR70633 $33.05
c) TT23482 $12.50
d) TAR51902 $66.44
e) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TAT18030 $1,164.16
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE38558 $143.61
2)Head Gasket Set TRE38847 $96.05
3) Head Gasket TR98461 $33.99
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78
6) Exhaust Manifold Gsk TR90658 $3.09
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TT23471 $9.57 x4
2) Bolt, Con Rod TR74194 $2.78 x8 3
3) Bush, Bal. Shaft TR57160 $5.70 x6 6 TR91708 $11.18 x6 7
4) Bal. Shaft R/H TRE26282 $222.05 R/H
5) Bal. Shaft L/H TRE26283 $222.05 L/H
6) Camshaft TR82820 $211.09 5
7) Bal. Shaft Stop TR88112
8) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Pump, Oil Tube TR113752 $11.93
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1)
Thermostat TRE33705 $10.66
180° F 4
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 Water

Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX504 $11.61
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Do not use with Flywheel Housing (m) T20300, T22991.
(3): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410.
(4): Do not use with Housing (m) R54096, R70741, R74549.
(5): Threaded Type.
(6): TR57160, (Inner Diam 0.5 mm / 0.020 in).
(7): TR91708, (Outer Diam. 2.00 mm / 0.078 in). O/S

Page 12
JOHN DEERE 4.202 O’RINGS ON BLOCK

Engine Desc: From 158,258

Engine Data: O'rings on Block Engine Dimensions: Bore: 3.86 in / 98 mm (2) Pin Ø: 1.1878 in / (+/- .0001) = 30mm Block (M): R53230, R53250, R55034, R72973, T32342

Con Rod (M): RE19733 (SUB FOR AT18005) Piston (M): T23481

Farm Tractors 2020 2120 2510

Backhoe Loaders 400 Forklifts 480

Skidders 440

Engine Series: 300 Engine Model: 4.202

1) Engine O/H Kit TOK4591 $997.30
2) Engine I/F Kit TIK4591 $851.05 SPEC SHEET - 4.202

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TAT18030 $1,164.16
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T)

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Piston-Liner Kit TAR71591 $162.02 Consists of:
a) TT23481 $70.48
b) TAR70633 $33.05
c) TT23482 $12.50
d) TT32340 $60.49
e) TAR71617 $9.12
f) TR51112 $1.06

1) O/H Gasket Set TRE38558 $143.61
2)Head Gasket Set TRE38847 $96.05
3) Head Gasket TR98461 $33.99
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78
6) Exhaust Manifold Gsk TR90658 $3.09
7) Gasket Thermostat Housing TT20219 $0.75

Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4

1) Bush, Con Rod TT23471 $9.57 x4
2) Bolt, Con Rod TR74194 $2.78 x8 3

3) Bush, Bal. Shaft TR57160 $5.70 x6 6 TR91708 $11.18 x6 7
4) Bal. Shaft R/H TRE26282 $222.05 R/H
5) Bal.Shaft L/H TRE26283 $222.05 L/H
6) Camshaft TR82820 $211.09 5
7) Bal. Shaft Stop TR88112
8) Con Rod TAT18005 $87.01
1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1

1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Pump, Oil Tube TR113752 $11.93
6) Oil Pump O'Ring TR61871 $1.57

1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 4

1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F 4
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX504 $11.61
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Do not use with Flywheel Housing (m) T20300, T22991.
(2): Always verify Bore diameter, on Block Replacement is 4.016”/102mm.
(3): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410.
(4): Do not use with Housing (m) R54096, R70741, R74549.
(5): Threaded Type.
(6): TR57160, (Inner Diam 0.5 mm / 0.020 in).
(7): TR91708, (Outer Diam. 2.00 mm / 0.078 in). O/S

Page 13
JOHN DEERE 4.219 SMALL PIN, O’RINGS ON LINER

Engine Desc: To ESN 275,483

Engine Data: O'rings on Liner Small Pin Engine Info: 4 Cyl

Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm Con Rod (M): T20007, R81410

Piston (M): RE53265 Farm Tractors 2520 Skidders 440A

Engine Series: 300 Engine Model: 4.219

1) Engine O/H Kit TOK4310 $1,131.71
2) Engine I/F Kit TIK4310 $975.65 SPEC SHEET - 4.219 Piston-Liner Kit TPLK310 $182.40 Consists of:
a) TAR78310 $85.39
b) TAR55759 $26.30
c) TT26149 $5.47
d) TAR51903 $67.96
e) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18030 $1,164.16
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE501579 $121.26
2) Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78
6) Gasket,
Injection Pump TR125066 $2.62
7) Gasket,

Turbo Mount TR89879 $7.48 1) Bush, Con Rod TT23471 $9.57 x4
2) Bolt, Con Rod TR74194 $2.78 x8 1
3) Bush, Bal. Shaft TR57160 $5.70 4 TR91708 $11.18 x6 6
4) Bal. Shaft R/H TRE26282 $222.05 R/H
5) Bal.Shaft L/H TRE26283 $222.05 L/H
6) Camshaft TR82820 $211.09 3
7) Bal. Shaft Stop TR88112
8) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Pump, Oil Tube TR113752 $11.93
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F 2
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 1) Water Pump TAT27018 $299.99 5
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX504 $11.61
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR5193

(1): Use TR74194, with C.Rod (m) T20007; use TR80033, with
C.Rod (m) R81410.
(2): Do not use with Housing (m) R54096, R70741, R74549.
(3): Threaded Type.
(4): TR57160, (Inner Diam 0.5 mm / 0.020 in).
(5): (m) R48997, (m) R51039.
(6): TR91708, (Outer Diam. 2.00 mm / 0.078 in). O/S

Page 14
JOHN DEERE 4.219 SMALL PIN, O’RINGS ON BLOCK

Engine Desc: To ESN 275,483

Engine Data: O'rings on Block Small Pin Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm

Block (M): T32342 Con Rod (M): T20007, R81410

Piston (M): RE53265, T30015, R51451, AR78310 Cotton Pickers 499

Farm Tractors 2030 2120 Windrowers 2270 2320 2420

Backhoe Loaders 401 401A Crawler Dozers 450A 450B

Skidders 440 440B

Forklifts 480A

Engine Series: 300 Engine Model: 4.219

1) Engine O/H Kit TOK4593 $959.03
2) Engine I/F Kit TIK4593 $847.87 SPEC SHEET - 4.219 Piston-Liner Kit TAR71593 $163.43 Consists of:
a) TAR78310 $85.39
b) TAR55759 $26.30
c) TT26149 $5.47
d) TR116463 $64.39
e) TAR71618 $7.95
f) TR51112 $1.06 Main
Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18030 $1,164.16
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE501579 $121.26
2) Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78
6) Gasket, Injection Pump TR125066 $2.62
7) Gasket, Turbo Mount TR89879 $7.48 1) Bush, Con Rod TT23471 $9.57 x4
2) Bolt, Con Rod TR74194 $2.78 x8 1
3) Bush, Bal. Shaft TR57160 $5.70 x6 4 TR91708 $11.18 x6 6
4) Bal. Shaft R/H TRE26282 $222.05 R/H
5) Bal.Shaft L/H TRE26283 $222.05 L/H
6) Camshaft TR82820 $211.09 3
7) Bal. Shaft Stop TR88112
8) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Pump, Oil Tube TR113752 $11.93
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F 2
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 1) 1) Water Pump
TAT27018 $299.99 5
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX504 $11.61
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410.
(2): Do not use with Housing (m) R54096, R70741, R74549.
(3): Threaded Type.
(4): TR57160, (Inner Diam 0.5 mm / 0.020 in).
(5): (m) R48997, (m) R51039.
(6): TR91708, (Outer Diam. 2.00 mm / 0.078 in). O/S

Page 15
JOHN DEERE 4.219 LARGE PIN, O’RINGS ON BLOCK

Engine Desc: From ESN 275,484 Engine Data: O'rings on Block Large Pin

Engine Info: 4 Cyl Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm Con Rod (M): R51727, R80034 Please see page 429 for a complete list of equipment models.

Engine Series: 300 Engine Model: 4.219 (1)

1) Engine O/H Kit TAT86984 $1,040.93
2) Engine I/F Kit TIK86984 $948.36 SPEC SHEET - 4.219 Piston-Liner Kit TAR78041 $151.32 Consists of:
a) TAR77762 $77.10
b) TAR55759 $26.30
c) TR125754 $12.08
d) TR116463 $64.39
e) TAR71618 $7.95
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18030 $1,164.16
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE501579 $121.26
2) Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78
6) Gasket, Injection Pump TR125066 $2.62
7) Gasket, Turbo Mount TR89879 $7.48 1) Bush, Con Rod TR55647 $8.00 x4
2) Bolt, Con Rod TR74194 $2.78 x8 2
3) Bush, Bal. Shaft TR57160 $5.70 x6 5 TR91708 $11.18 x6 8
4) Bal. Shaft R/H TRE26282 $222.05 R/H
5) Bal.Shaft L/H TRE26283 $222.05 L/H
6) Camshaft TR82820 $211.09 4
7) Bal. Shaft Stop TR88112
8) Con Rod TRE16495 $92.02 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Pump, Oil Tube TR113752 $11.93
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F 3
2) Thermostat Cover TT23620 $15.12
3) Water Temp Sensor TRE51774 $27.68 7
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 1) Water Pump TAT27018 $299.99 6
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX504 $11.61
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Some of these engines maybe turbocharged.
(2): For Connecting Rods TRE16495 $92.02 and RE21076 Use Connecting Rod Bolt TR80033.
(3): Do not use with Housing (m) R54096, R70741, R74549.
(4): Threaded Type.
(5): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in).
(6): (m) R48997, (m) R51039.
(7): Check for proper Application.
(8): TR91708 $11.18 (Outer Diam. 2.00 mm / 0.078 in). O/S

Page 16
JOHN DEERE 4.239D

Engine Info: 4 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm Con Rod (M): R80034 Piston (M): RE30250 Please see page 430 for a complete list of equipment models.

Engine Series: 300 Engine Model: 4.239D

1) Engine O/H Kit TAT86992 $956.41
2) Engine I/F Kit TIK86992 $908.57 SPEC SHEET - 4.239D Piston-Liner Kit TRE30250 $161.15 Consists of:
a) TRE19282 $107.84
b) TRE66820 $26.88
c) TR125754 $12.08
d) TR116281 $70.79
e) TAR65507 $7.24
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18030 $1,164.16 1 TRE20585 $1,201.08 2
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501579 $121.26
2) Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78
6) Gasket, Injection Pump TR125066 $2.62
7) Gasket, Turbo Mount TR89879 $7.48 1) Bush, Con Rod TR55647 $8.00 x4
2) Bolt, Con Rod TR80033 $3.60 x8 3
3) Bush, Bal. Shaft TR57160 $5.70 x6 5
TR91708 $11.18 x6 11
4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 10
5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 10
6) Camshaft TR82820 $211.09 4
7) Bal Shaft Stop TR88112
8) Con Rod TRE16495 $92.02
9) Cam Bearing TR119874 $11.12 9 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16 8
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Pump, Oil Tube TR113752 $11.93 8
6) Cyl Hd Cap Screw TR85363 $3.42 x18 6
7) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TRE33705 $10.66
180° F
2) Thermostat Cover TT23620 $15.12
3) Water Temp Sensor TRE51774 $27.68 8
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 1) Water Pump TAR97708U $249.40 7 TAR92641 $523.16 8 TAR97717 $762.08 8
2)Water Pump Gasket TT20242 $3.83 TT20268 $4.92

Transmission Oil
Pump
TAL120106 $714.81 8 TAL68094 $681.20 8 Transmission Oil Pump TAL120106 $714.81 TAL68094 $681.20 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX504 $11.61
4) Glow Plug TRE502079 $34.28
5) Cap TAT27622 $6.18 TAR85618 $8.44
6) Washer TT29539 $0.46
7) Tube 7Nut TR5193

(1): TAT18030 $1,164.16 Crankshaft 36mm (short) snout, (m) T23517.
(2): TRE20585 $1,201.08 Crankshaft 60mm (long) snout, (m) R81959 or R121018.
(3): For Connecting Rod (m) R58979, use TR74194 $2.78 Connecting Rod Bolt available upon request.
(4): Threaded Type.
(5): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in).
(6): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.
(7): (m) R73604.
(8): Check for proper application.
(9): The cam bearing is used in the late style blocks and it is not included in the overhaul kit.
(10): These shafts are made for bolt on weights.
(11): TR91708 $11.18 (Outer Diam. 2.00 mm / 0.078 in). O/S

Page 17
JOHN DEERE 4039D LITER DESIGNATED

Engine Desc: Liter Designated

Engine Info: 4 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm Block (M): R88984

Con Rod (M): R80034

Piston (M): RE30250, RE18697 Farm Tractors 5600

Backhoe Loaders 210D 310C 310D 315C 315D 515B Excavators 290D 70D

Crawler Dozers 400G

Forklifts 482C

Engine Series: 300 Engine Model: 4039D Engine

1) Engine O/H Kit TAT86992 $956.41
2) Engine I/F Kit TIK86992 $908.57 SPEC SHEET - 4039D Piston-Liner Kit TRE30250 $161.15 Consists of:
a) TRE19282 $107.84
b) TRE66820 $26.88
c) TR125754 $12.08
d) TR116281 $70.79
e) TAR65507 $7.24
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18030 $1,164.16 13 TRE20585 $1,201.08 14
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501579 $121.26
2) Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78 3 $21.78 TR106796 $10.02 3
6) Gasket, Injection Pump TR125066 $2.62
7) Gasket, Turbo Mount TR89879 $7.48 1) Bush, Con Rod TR55647 $8.00 x4
2) Bolt, Con Rod TR80033 $3.60 x8
3) Bush, Bal. Shaft TR57160 $5.70 x6 4
TR91708 $11.18 x6 16
4) Bal. Shaft R/H TRE26282 $222.05 15 TAR69710 $320.74
5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 15
6) Camshaft TR82820 $211.09 8 $188.47
7) Camshaft Kit TRE55901 $265.90 12
8) Con Rod TRE16495 $92.02
9) Cam Bearing TR119874 $11.12 1) Pump, Oil TRE55343 $131.62 2
2) Oil Cooler TRE31929 $228.16
3) Pump, Oil Tube TR113752 $11.93
4) Cyl Hd Cap Screw TR85363 $3.42 x18 1
5) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41 6
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74 6
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54 6 $102.27

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S.
2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

1) Thermostat TAR48675 $14.80
180° F 5
2) Thermostat Cover TT23620 $15.12
3) Water Temp Sensor TRE51774 $27.68 11
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $50.45 11 TRE38009 $69.25 7 TRE55390 $46.60 11
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 1) Water Pump TAR97708U $249.40 9 TRE60489 $227.48 10 TRE16666 $728.31 11 TAR92641 $523.16 11 TAR97717 $762.08 11
2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE36936 $59.20
3) KIT, GROMMET TMX504 $11.61
4) Glow Plug TRE502079 $34.28

(1): Replace all R78558 Cap Screws with Flanged Head Cap Screw
TR85363.
(2): May use High cap. Pump, Oil TRE65580.
(3): O’ring not included in Gasket Set. Used in Saran Engines. Order
separately.
(4): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in)
(5): Saran engines may use TRE64354.
(6): Helicoidal Gears.
(7): Saran Engines.
(8): Threaded Type.
(9): (m) R73604.
(10): (m) R100812, (m) R127337, (m) R127918, (m) R55164.
(11): Check application for proper usage.
(12): For Late 4039 models.
(13): TAT18030 $1,164.16 Crankshaft 36mm (short) snout, (m) T23517.
(14): TRE20585 $1,201.08 Crankshaft 60mm (long) snout, (m) R81959 or R121018.
(15): These shafts are made for bolt on weights.
(16): TR91708 $11.18 (Outer Diam. 2.00 mm / 0.078 in). O/S

Page 18
JOHN DEERE 4.239T

Engine Info: 4 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .0002) = 41mm Con Rod (M): R80032, R113612, R122191 Piston (M): RE19278 Please see page 431 for a complete list of equipment models.

Engine Series: 300 Engine Model: 4.239T

1) Engine O/H Kit TRE54709 $1,107.22
2) Engine I/F Kit TIK54709 $1,016.74 SPEC SHEET - 4.239T Piston-Liner Kit TRE33115 $161.15 Consists of:
a) TRE19278 $107.84
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR116281 $70.79
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18030 $1,164.16 1 TRE20585 $1,201.08 4
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501579 $121.26
2) Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78
6) Gasket, Injection Pump TR125066 $2.62
7) Gasket, Turbo Mount TR89879 $7.48 1) Bush, Con Rod TR57451 $11.38 x4
2) Bolt, Con Rod TR80033 $3.60 x8
3) Bush, Bal. Shaft TR57160 $5.70 x6 3 TR91708 $11.18 x6 11
4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 10
5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 10
6) Camshaft TR82820 $211.09 5 $188.47
7) Bal Shaft Stop TR88112
8) Con Rod TRE58347 $103.07
9) Kit, Piston Pin TRE63913 $27.07 x4
10) Cam Bearing TR119874 $11.12 9 1) Pump, Oil TRE55343 $131.62 2
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Pump, Oil Tube TR113752 $11.93
6) Cyl Hd Cap Screw TR85363 $3.42 x18 6
7) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR83071 $15.56 Std. TR89223 $19.73 0.003 TR89224 $17.44 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

1) Thermostat TAR48675 $14.80
180° F
2) Thermostat Cover TT23620 $15.12
3) Water Temp Sensor TRE51774 $27.68 8
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 1) Water Pump Repair Kit See Chart
2) Turbocharger TRE26287 $695.39 8 Water Pump TAR97708U $249.40 7 TAR92641 $523.16 8 TAR97717 $762.08 8 Transmission Oil Pump TAL120106 $714.81 TAL6809
1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE3750
3) KIT, GROMMET TMX504 $11.61
4) Glow Plug TRE502079 $34.28

(1): TAT18030 $1,164.16 Crankshaft 36mm (short) snout, (m) T23517.
(2): May use High cap. Pump, Oil TRE65580.
(3): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in).
(4): TRE20585 $1,201.08 Crankshaft 60mm (long) snout, (m) R81959 or R121018.
(5): Threaded Type.
(6): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.
(7): (m) R73604.
(8): Check your application for proper usage.
(9): The cam bearing is used in the late style blocks and it is not included in
the overhaul kit.
(10): These shafts are made for bolt on weights.
(11): TR91708 $11.18 (Outer Diam. 2.00 mm / 0.078 in) O/S

Page 19
JOHN DEERE 4039T LITER DESIGNATED

Engine Desc: Liter Designated
Engine Info: 4 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .0002) = 41mm Con Rod (M): R80032, R122191, R113612

Piston (M): RE19278 Farm Tractors 5500N 5700 6200 6200L SE6200 6210 6300 6300L SE6300 6310 Backhoe Loaders 300D 310C 315C 315D 515B

Engine Series: 300 Engine Model: 4039T

1) Engine O/H Kit TRE54709 $1,107.22
2) Engine I/F Kit TIK54709 $1,016.74 SPEC SHEET - 4039T Piston-Liner Kit TRE33115 $161.15 Consists of:
a) TRE19278 $107.84
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR116281 $70.79
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT18030 $1,164.16 13 TRE20585 $1,201.08 14
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501579 $121.26
2) Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78 2
TR106796 $10.02
6) Gasket, Injection Pump TR125066 $2.62
7) Gasket, Turbo Mount TR89879 $7.48 1) Bush, Con Rod TR57451 $11.38 x4
2) Bolt, Con Rod TR80033 $3.60 x8
3) Bush, Bal. Shaft TR57160 $5.70 x6 4
TR91708 $11.18 x6 16
4) Camshaft TR82820 $211.09 8
5) Con Rod TRE58347 $103.07
6) Bal Shaft R/H TRE26282 $222.05 TAR69710 $320.74 15
7) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 15
8) Camshaft Kit TRE55901 $265.90 12
9) Kit, Piston Pin TRE63913 $27.07 x4
10) Cam Bearing TR119874 $11.12 1) Pump, Oil TRE55343 $131.62 3
2) Oil Cooler TRE31929 $228.16 11
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Pump, Oil Tube TR113752 $11.93
6) Cyl Hd Cap Screw TR85363 $3.42 x18 1
7) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41 6
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89 6
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54 6

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 O/S TR98335 $30.57 O/S
2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

1) Thermostat
TAR48675 $14.80 180¢X F 5
2) Thermostat Cover
TT23620 $15.12
3) Water Temp Sensor
TRE51774 $27.68 11
4) Thermostat Cover
Gsk
TT20215 $0.84 1) Fuel Transfer Pump
TRE42211 $56.51 11
TRE38009 $69.25 7
TRE55390 $46.60 11
2) Fuel Pump Gasket
TR27285 $1.31 1) Water Pump Repair
Kit
See Chart
2) Turbocharger
TRE26287 $695.39 11 Water Pump
TAR97708U $249.40 9
TRE60489 $227.48 10
TRE16666 $728.31 11
TRE41157 $228.62 11
TAR92641 $523.16 11
TAR97717 $762.08 11 1) Seal, Injector
TR60746 $0.38
TR48000 $1.06
2) Injector, Pencil
TRE38087 $77.63
3) KIT, GROMMET
TMX504 $11.61
4) Glow Plug
TRE502079 $34.28

(1): Replace all R78558 Cap Screws with Flanged Head Cap Screw
TR85363.
(2): Saran engines, O’ring not included in Gasket Set. Order separately.
(3): May use High cap. Pump, Oil TRE65580.
(4): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in).
(5): Saran engines may use TRE64354.
(6): Helicoidal Gears.
(7): Saran Engines.
(8): Threaded Type.
(9): (m) R73604.
(10): (m) R100812, (m) R127337, (m) R127918, (m) R55164.
(11): Check application for proper usage.
(12): For Late 4039 models.
(13): TAT18030 $1,164.16 Crankshaft 36mm (short) snout, (m) T23517.
(14): TRE20585 $1,201.08 Crankshaft 60mm (long) snout, (m) R81959 or R121018.
(15): These shafts are made for bolt on weights.

Page 20
JOHN DEERE 4.276D SMALL PIN

Engine Desc: Small Pin

Engine Info: 4 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.375 in / 35 mm Con Rod (M): R54617 Farm Tractors 2630 2640 Backhoe Loaders 410C

Engine Series: 300 Engine Model: 4.276D

1) Engine O/H Kit TAT86990 $1,041.36
2) Engine I/F Kit TIK86990 $963.44 SPEC SHEET - 4.276D Piston-Liner Kit TRE19831 $191.10 Consists of:
a) TAR63342 $113.25
b) TRE66820 $26.88
c) TR125754 $12.08
d) TR80500 $63.25
e) TAR65507 $7.24
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030 Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TRE56792 $1,260.57
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) TR28811 $67.53 (129T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501568 $135.66
2)Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78 1) Bush, Con Rod TR57450 $19.68 x4
2) Bolt, Con Rod TR74195 $4.74 x8 4
3) Bush, Bal. Shaft TR57160 $5.70 x6 TR91708 $11.18 x6 8
4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 7
$170.32
5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 7
$151.19 Camshaft TR82820 $211.09 2 1) Pump, Oil TRE65580 $202.70 1
2) Rocker Arm TRE3197
3) Rocker Shaft
TR5498
4) Cyl Hd Cap Screw TR85363 $3.42 x18 5 3 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

1) Thermostat TAR48675 $14.80
180° F
2) Thermostat Cover TT23620 $15.12
3) Water Temp Sensor TRE51774 $27.68 5
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 6 |
With Impeller TRE62658 $75.66 6 Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE37503 $59.20
3) KIT, GROMMET TMX504 $11.61

(1): This engine may use standard flow Pump, Oil TRE55343.
(2): Threaded Type.
(3): From ESN 137128 Replace all R78558 Cap Screws withFlanged
Head Cap Screw TR85363.
(4): When used on connecting rods marked R54617, torque bolts to
95 ft.lbs. Only.
(5): Check for proper application.
(6): See the Water Pump Identification Chart to make sure these part
numbers are correct. You will need the water pump casting number
and will need to know if you have a stamped steel pulley or a cast iron
pulley.
(7): These shafts are made for bolt on weights.
(8): O/S

Page 21
JOHN DEERE 4.276D LARGE PIN

Engine Desc: Large Pin
Engine Info: 4 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.625 in / 41 mm Wheel Loaders 344E

Backhoe Loaders 410C 410D 510B Crawler Dozers 450E 450G 455E 455G Excavators 490D 493D

Skidders 340D 440C

Engine Series: 300 Engine Model: 4.276D

1) Engine O/H Kit TRE63694 $1,102.84
2) Engine I/F Kit TIK63694 $937.09 SPEC SHEET - 4.276D Piston-Liner Kit TRE28966 $176.91 Consists of:
a) TRE28919 $88.28
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR80500 $63.25
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TRE56792 $1,260.57
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) TR28811 $67.53 (129T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501568 $135.66
2) Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78 1) Bush, Con Rod TR57451 $11.38 x4
2) Bolt, Con Rod TR74195 $4.74 x8 4
3) Bush, Bal. Shaft TR57160 $5.70 x6 TR91708 $11.18 6
$11.18 x6
4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 5
$170.32
5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 5
$151.19
6) Camshaft TR82820 $211.09 2
7) Kit, Piston Pin TRE63913 $27.07 x4
8) Con Rod TRE53716 $190.66 1) Pump, Oil TRE65580 $202.70 1
2) Rocker Arm TRE31973 $34.00
3) Rocker Shaft TR5498
4) Cyl Hd Cap Screw TR85363 $3.42 x18 3 1) Lower Gear
TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing 3TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02
2) Insert, Valve Ex TR51734 $12.96 Std. TR93910 $11.22 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

1) Thermostat TAR48675 $14.80
180° F
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 Water Pump Gasket TT20242 $3.83 TT20268 $4.92 1) Seal, Injector TR60746 $0.38 TR48000 $1.062)Injector, Pencil TRE37503 $59.20
3) KIT, GROMMET TMX504 $11.61

1): This engine may use standard flow Pump, Oil TRE55343.
(2): Threaded Type.
(3): From ESN 137128 Replace all R78558 Cap Screws withFlanged Head
Cap Screw TR85363.
(4): When used on connecting rods marked R56187, torque bolts to 95
ft.lbs. Only.
(5): These shafts are made for bolt on weights.
(6): O/S

Page 22
JOHN DEERE 4045D LITER DESIGNATED

Engine Desc: Liter Designated Engine Info: 4 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.625 in / 41 mm Please see page 432 for a complete list of equipment models.

Engine Series: 300 Engine Model: 4045D

1) Engine O/H Kit TRE63694 $1,102.84
2) Engine I/F Kit TIK63694 $937.09 Piston-Liner Kit TRE28966 $176.91 Consists of:
a) TRE28919 $88.28
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR80500 $63.25
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TRE56792 $1,260.57 10 TRE54883 $2,004.54
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) TR28811 $67.53 (129T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501568 $135.66
2)Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78 1) Bush, Con Rod TR57451 $11.38 x4 7
2) Bolt, Con Rod TR74195 $4.74 x8 7
3) Bush, Bal. Shaft TR57160 $5.70 x6 TR91708 $11.18 x6 13
4) Camshaft TR82820 $211.09 4
5) Bal Shaft R/H TRE26282 $222.05 TAR69710 $320.74 12
6) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 12
7) Kit, Piston Pin TRE63913 $27.07 x4
8) Con Rod TRE53716 $190.66
9) Camshaft Kit TRE55901 $237.42 11 1) Pump, Oil TRE65580 $202.70 1
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Cyl Hd Cap Screw TR85363 $3.42 x18 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S
2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

1) Thermostat TAR48675 $14.80
180° F 2
2) Thermostat Cover TT23620 $15.12
3) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE4221 TRE38009 $69.25 3
2) Fuel Pump Gasket TR27285 $1.31
3) Fuel Filter Base with Primer TRE67225 $159.99 Water Pump Repair Kit See Chart Water Pump TAR97708U $249.40 8
TRE60489 $227.48 9
TRE16666 $728.31 10 Water Pump TRE4157
1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE38087 $77.63
3) KIT, GROMMET TMX504 $11.61
4) Glow Plug TRE502079 $34.28

1): Saran engines use TRE55343 $131.62 Standard flow.
(2): Saran engines may use TRE64354.
(3): Saran Engines.
(4): Threaded Type.(5) Replace all R78558 Cap Screws with Flanged Head
Cap Screw TR85363.
(5): Replace all R78558 Cap Screws with Flanged Head Cap Screw
TR85363.
(6): Always verify Oil Cooler Type.
(7): When used on connecting rods marked R56187, torque bolts to 95
ft.lbs.
(8): (m) R73604.
(9): (m) R100812, (m) R127337, (m) R127918, (m) R55164.
(10): Crankshaft (m) R54501. This Engines model may also use crankshaft
TRE54883 $2,004.54 60mm Snout; (m) R90825, R120009. PLEASE VERIFY.
(11): For Late 4039 models.
(12): These shafts are made for bolt on weights.
(13): O/S

Page 23
JOHN DEERE 4.276T

Engine Info: 4 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.625 in / 41 mm Please see page 433 for a complete list of equipment models.

Engine Series: 300 Engine Model: 4.276T

1) Engine O/H Kit TRE61612 $1,102.84
2) Engine I/F Kit TIK61612 $1,023.18 SPEC SHEET - 4.276T Piston-Liner Kit TRE53073 $183.95 Consists of:
a) TRE48469 $92.70
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR80500 $63.25
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TRE56792 $1,260.57
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) TR28811 $67.53 (129T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501568 $135.66
2) Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78
TR106796 $10.02 7 1) Bush, Con Rod TR57451 $11.38 x4 5
2) Bolt, Con Rod TR74195 $4.74 x8
3) Bush, Bal. Shaft TR57160 $5.70 x6 TR91708 $11.18 X6 9 4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 8
5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 8
6) Camshaft TR82820 $211.09 3
7) Kit, Piston Pin TRE63913 $27.07 x4
8) Con Rod TRE53716 $190.66 1) Pump, Oil TRE65580 $202.70 1
2) Rocker Arm TRE31973 $34.00
3) Rocker Shaft TR54987
4) Cyl Hd Cap Screw TR85363 $3.42 x18 4
5) Tensioner Belt TAL110621 $99.41 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR83071 $15.56 Std. TR89223 $19.73 0.003 TR89224 $17.44 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve
TR87627 $0.48

1) Thermostat TAR48675 $14.80
180° F
2) Thermostat Cover TT23620 $15.12
3) Water Temp Sensor TRE51774 $27.68 6
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 1) Water Pump Repair Kit Without Impeller TRE19510 $69.50 With Impeller TRE11348 $101.78
2)Turbocharger TRE26287 $695.39 6 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE3750
3) KIT, GROMMET TMX504 $11.61

(1): This engine may use Standard Flow Pump, Oil TRE55343.
(2): Do not use 45 degree Valves with RE56545 Head.
(3): Threaded Type
(4): From ESN 137128 Replace all R78558 Cap Screws with Flanged Head
Cap Screw TR85363 $3.42
(5): When used on connecting rods marked R56187, torque bolts to 95
ft.lbs. Only.
(6): Check for proper application
(7): Saran engines, O’ring not included in Gasket Set. Order separately.
(8): These shafts are made for bolt on weights.
(9): O/S

Page 24
JOHN DEERE 4045T LITER DESIGNATED

Engine Desc: Liter Designated Engine Info: 4 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.625 in / 41 mm Please see page 434 for a complete list of equipment models.

Engine Series: 300 Engine Model: 4045T

1) Engine O/H Kit TRE61612 $1,102.84
2) Engine I/F Kit TIK61612 $1,023.18 SPEC SHEET - 4045T Piston-Liner Kit TRE53073 $183.95 Consists of:
a) TRE48469 $92.70
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR80500 $63.25
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 4 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030
Use 4

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TRE56792 $1,260.57 11
$2,698.74 TRE54883 $2,004.54
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) TR28811 $67.53 (129T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501568 $135.66
2)Head Gasket Set TRE38851 $70.33
3) Head Gasket TR125863 $39.74
4) Oil Pan Gasket TR97342 $14.21
5) Rocker Cover Gsk TR73521 $21.78 TR106796 $10.02 13 1) Bush, Con Rod TR57451 $11.38 x4
2) Bolt, Con Rod TR74195 $4.74 x8 7
3) Bush, Bal. Shaft TR57160 $5.70 x6 TR91708 $11.18 x6 15
4) Camshaft TR82820 $211.09 4
5) Bal Shaft R/H TRE26282 $222.05 TAR69710 $320.74 14
6) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 14
7) Kit, Piston Pin TRE63913 $27.07 x4
8) Con Rod TRE53716 $190.66
9) Camshaft Kit TRE55901 $265.90 12 1) Pump, Oil TRE65580 $202.70 1
2) Oil Cooler TRE31929 $228.16 6
3) Rocker Arm TRE31973 $34.00
4) Rocker Shaft TR54987
5) Cyl Hd Cap Screw TR85363 $3.42 x18 5
6) Tensioner Belt TAL110621 $99.41 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower 5TT20073 $11.56 x8
6) Cam. Gear TT20070 $114.54

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S
2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

1) Thermostat TAR48675 $14.80
180° F 2
2) Thermostat Cover TT23260
3) Water Temp Sensor TRE51774 $27.68 1) Fuel Transfer Pump TRE42211 $56.51 TRE38009 $69.25 3
$69.25 3
2) Fuel Pump Gasket TR27285 $1.31
3) Fuel Filter Base with Primer TRE67225 $159.99 1) Water Pump TAR97708U $249.40 9
TRE60489 $227.48 9
TRE16666 $728.31 10
TRE41157 $228.62 10
2) Water Pump Repair Kit
See Chart Turbocharger TRE26287 $695.39 10
TR58898 10 1) Seal, Injector 10 10TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE38087 $77.63
3) KIT, GROMMET TMX504 $11.61
4) Glow Plug TRE502079 $34.28

(1): Saran engines use TRE55343 $131.62 Standard flow.
(2): Saran engines may use TRE64354.
(3): Saran Engines.
(4): Threaded Type.
(5): Replace all R78558 Cap Screws with Flanged Head Cap Screw
TR85363.
(6): Always verify Oil Cooler Type.
(7): When used on connecting rods marked R56187, torque bolts to 95
ft.lbs.
(8): (m) R73604.
(9): (m) R100812, (m) R127337, (m) R127918, (m) R55164.
(10): Check application for proper usage.
(11): Crankshaft (m) R54501. This Engines model may also use crankshaft
TRE54883 $2,004.54 60mm Snout; (m) R90825, R120009. PLEASE VERIFY.
(12): For Late 4039 models.
(13): Saran engines, O’ring not included in Gasket Set. Order separately.
(14): These shafts are made for bolt on weights.
(15): O/S

Page 25
JOHN DEERE 6.303 O’RINGS ON LINER

Engine Desc: To ESN 158,975

Engine Data: O'rings on Liner Engine Dimensions: Bore: 3.86 in / 98 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm Block (M): T24967, T24968 Con Rod (M): T20007, R81410 Piston (M): T23481

Wheel Loaders 544

Engine Series: 300 Engine Model: 6.303

1) Engine O/H Kit TOK6481 $1,526.66
2) Engine I/F Kit TIK6481 $1,415.29 SPEC SHEET - 6.303 Piston-Liner Kit TPLK481 $173.99 Consists of:
a) TT23481 $70.48
b) TAR70633 $33.05
c) TT23482 $12.50
d) TAR51902 $66.44
e) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TAT22562 $2,118.73
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE38568 $257.07
2)Head Gasket Set TRE38571 $179.15
3) Head Gasket TR98462 $76.50
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84 1) Bush, Con Rod TT23471 $9.57 x6
2) Bolt, Con Rod TR74194 $2.78 x12 2
3) Camshaft TR82821 $377.62 3
4) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Pump, Oil Tube TR113752 $11.93
5) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

Thermostats
TAR70601
180° F 4
TAR77411 $139.39
1195ºF 4 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19510 $69.50 With Impeller TMX132 $84.43 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX506 $17.41
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Do not use with flywheel housing (m) T20300,T22991.
(2): Use TR74194 $2.78 with C.Rod (m) T20007; use TR80033 $3.60 with C.Rod
(m) R81410.
(3): Threaded Type. (4): Verify JD parts manual.

Page 26
JOHN DEERE 6.303 O’RINGS ON BLOCK

PistEngine Desc: From ESN 158,976

Engine Data: O'rings on Block Engine Dimensions: Bore: 3.86 in / 98 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm Block (M): R53260, R55035, R55351, R72970, R79280, T32346 Con Rod (M): T20007, R81410 on (M): T23481 Farm Tractors 3420 Skidders 540

Wheel Loaders 544

Engine Series: 300 Engine Model: 6.303

1) Engine O/H Kit TOK6591 $1,498.75
2) Engine I/F Kit TIK6591 $1,262.76 SPEC SHEET - 6.303 Piston-Liner Kit TAR71591 $162.02 Consists of:
a) TT23481 $70.48
b) TAR70633 $33.05
c) TT23482 $12.50
d) TT32340 $60.49
e) TAR71617 $9.12
f) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TAT22562 $2,118.73
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE38568 $257.07
2)Head Gasket Set TRE38571 $179.15
3) Head Gasket TR98462 $76.50
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84 1) Bush, Con Rod TT23471 $9.57 x6
2) Bolt, Con Rod TR74194 $2.78 x12 2
3) Camshaft TR82821 $377.62 3
4) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Pump, Oil Tube TR113752 $11.93
5) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

Thermostats
TAR70601 180° F 4
TAR77411 $139.39 195º F 4 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19510 $69.50 With Impeller TMX132 $84.43 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX506 $17.41
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Do not use with flywheel housing (m) T20300,T22991.
(2): Use TR74194 $2.78 with C.Rod (m) T20007; use TR80033 $3.60 with C.Rod (m) R81410.
(3): Threaded Type.
(4): Verify JD parts manual.

Page 27
JOHN DEERE 6.329 SMALL PIN, O’RINGS ON LINER

Engine Desc: To ESN 277,548

Engine Data: O'rings on Liner Small Pin Engine Info: 6 Cyl, Block (m) T24968 Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm Con Rod (M): T20007, R81410

Piston (M): RE53265, T30015, R51451, AR78310 Farm Tractors 3120 Skidders 540A

Cotton Pickers 699

Engine Series: 300 Engine Model: 6.329

1) Engine O/H Kit TOK6310 $1,614.63
2) Engine I/F Kit TIK6310 $1,050.54 SPEC SHEET - 6.329 Piston-Liner Kit TPLK310 $182.40 Consists of:
a) TAR78310 $85.39
b) TAR55759 $26.30
c) TT26149 $5.47
d) TAR51903 $67.96
e) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT22562 $2,118.73
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TT23471 $9.57 x6
2) Bolt, Con Rod TR74194 $2.78 x12 1
3) Camshaft TR82821 $377.62 2
4) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Pump, Oil Tube TR113752 $11.93
5) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

Thermostats
TAR70601 180° F 3
TAR77411 $139.39 195º F 3 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TMX9398 $97.32 With Impeller TMX131 $121.68 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX506 $17.41
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Use TR74194 $2.78 with C.Rod (m) T20007; use TR80033 $3.60 with C.Rod (m) R81410.
(2): Threaded Type.
(3): Verify JD parts manual.

Page 28
JOHN DEERE 6.329 SMALL PIN, O’RINGS ON BLOCK

Engine Desc: To ESN 277,549

Engine Data: O'rings on Block Small Pin Engine Info: 6 Cyl

Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm Con Rod (M): T20007, R81410

Piston (M): RE53265, T30015, AR78310 Cotton Pickers 499 699

Farm Tractors 3120 4030 4420 Wheel Loaders 544A

Motor Graders 570A Skidders 540A

Engine Series: 300 Engine Model: 6.329

1) Engine O/H Kit TOK6593 $1,447.16
2) Engine I/F Kit TIK6593 $1,249.86 SPEC SHEET - 6.329 Piston-Liner Kit TAR71593 $163.43 Consists of:
a) TAR78310 $85.39
b) TAR55759 $26.30
c) TT26149 $5.47
d) TR116463 $64.39
e) TAR71618 $7.95
f) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT22562 $2,118.73
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51 1
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TT23471 $9.57 x6
2) Bolt, Con Rod TR74194 $2.78 x12 2
3) Camshaft TR82821 $377.62 3
4) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Pump, Oil Tube TR113752 $11.93
5) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

Thermostats
TAR70601 180° F 4
TAR77411 $139.39
195º F 4 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TMX9398 $97.32 With Impeller TMX131 $121.68 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX506 $17.41
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): For Tractor Model 4030 order TR97345.
(2): Use TR74194 $2.78 with C.Rod (m) T20007; use TR80033 $3.60 with C.Rod (m) R81410.
(3): Threaded Type.
(4): Verify JD parts manual.

Page 29
JOHN DEERE 6.329 LARGE PIN, O’RINGS ON BLOCK

Engine Desc: From ESN 277,549

Engine Data: O'rings on Block Large Pin

Engine Info: 6 Cyl Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm

Con Rod (M): RE16495 Piston (M): AR77762

Cotton Pickers 499

Combines 950 960 4400 Farm Tractors 2840 3130 3530 4030 4425

Wheel Loaders 444 444C 444D 444CH 544A Motor Graders 570A

Backhoe Loaders 710B

Engine Series: 300 Engine Model: 6.329

1) Engine O/H Kit TAT86986 $1,415.29
2) Engine I/F Kit TIK86986 $1,352.92 SPEC SHEET - 6.329 Piston-Liner Kit TAR78041 $151.32 Consists of:
a) TAR77762 $77.10
b) TAR55759 $26.30
c) TR125754 $12.08
d) TR116463 $64.39
e) TAR71618 $7.95
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT22562 $2,118.73
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR114282 $39.11 (142T) 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51 1
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TR55647 $8.00 x6
2) Bolt, Con Rod TR74194 $2.78 x12
3) Camshaft TR82821 $377.62 2
4) Con Rod TRE16495 $92.02 3 1) Pump, Oil TRE55343 $131.62
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Pump, Oil Tube TR113752 $11.93
5) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

1) Thermostats
TAR70601 180° F 5 TAR77411 $139.39 195ºF 5 TRE33705 $10.66 180ºF 5
2) Water Temp Sensor TRE51774 $27.68 4 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TMX9398 $97.32 With Impeller TMX131 $121.68 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX506 $17.41
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): For Tractor Model 4030 order TR97345.
(2): Threaded Type.
(3): For Connecting Rods RE16495 and RE21076 Use Connecting Rod Bolt TR80033.
(4): Check for proper application.
(5): Verify JD parts manual.

Page 30
JOHN DEERE 6.359D

Engine Info: 6 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm Con Rod (M): R80034 Piston (M): RE30250 Please see page 435 for a complete list of equipment models.

Engine Series: 300 Engine Model: 6.359D

1) Engine O/H Kit TRE50784 $1,383.91
2) Engine I/F Kit TIK50784 $1,247.90 SPEC SHEET - 6059D, 6.359D Piston-Liner Kit TRE30250 $161.15 Consists of:
a) TRE19282 $107.84
b) TRE66820 $26.88
c) TR125754 $12.08
d) TR116281 $70.79
e) TAR65507 $7.24
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TAT22562 $2,118.73
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR28811 $67.53 (129T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TR55647 $8.00 x6
2) Bolt, Con Rod TR80033 $3.60 x12
3) Camshaft TR82821 $377.62 3
4) Con Rod TRE16495 $92.02 1) Pump, Oil TRE55343 $131.62 2
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00
4) Pump, Oil Tube TR113752 $11.93
5) Cyl Hd Cap Screw TR85363 $3.42 x26 4
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 x12
6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

1) Thermostat TAR48675 $14.80
180° F 1
2) Water Temp Sensor TRE51774 $27.68 6 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit See Chart Water Pump
TRE31600 $451.79 5
TRE97717 6

Transmission Oil Pump
TAL120106 $714.81
TAL68094 $681.20 1) Seal, Injector
TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR89564 $59.20
3) Kit, Grommet TMX506 $17.41
4) Cap TAT27622 $6.18 TAR85618 $8.44
5) Washer TT29539 $0.46
6) Tube Nut TR51937 $5.77

(1): Saran engines may use TRE64354.
(2): Some Engines Models may use High Capacity Pump, Oil TRE65580.
(3): Threaded Type.
(4): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.
(5): Check serial number for proper application.
(6): Check for proper application.

Page 31
JOHN DEERE 6059D LITER DESIGNATED

Engine Desc: Liter Designated

Engine Info: 6 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm Con Rod (M): R80034

Piston (M): RE30250 Farm Tractors 2955 3155 3155TSS 3255 3640 3650

Cotton Pickers 9900 9910 9920 Wheel Loaders 444D

Motor Graders 570B

Engine Series: 300 Engine Model: 6059D

1) Engine O/H Kit TRE50784 $1,383.91
2) Engine I/F Kit TIK50784 $1,247.90 SPEC SHEET - 6059D, 6.359D Piston-Liner Kit TRE30250 $161.15 Consists of:
a) TRE19282 $107.84
b) TRE66820 $26.88
c) TR125754 $12.08
d) TR116281 $70.79
e) TAR65507 $7.24
f) TM41029 $1.07 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT22562 $2,118.73
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR28811 $67.53 (129T) TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TR55647 $8.00 x6
2) Bolt, Con Rod TR80033 $3.60 x12
3) Camshaft TR82821 $377.62 7
4) Con Rod TRE16495 $92.02 1) Pump, Oil TRE55343 $131.62 2
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00 5
4) Pump, Oil Tube TR113752 $11.93
5) Cyl Hd Cap Screw TR85363 $3.42 X26 1
6) Oil Pump O'Ring TR61871 $1.57 1) Lower Gear TAT24252 $117.41 4
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74 4
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54 4

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S
2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

1) Thermostat TAR48675 $14.80 3
180° F
2) Water Temp Sensor TRE51774 $27.68 9 1) Fuel Transfer Pump TRE42211 $56.51 6
TRE38009 $69.25
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit See Chart Water Pump TAR97708U $249.40 8
TRE16666 $728.31 9
TAR92641 $523.16 9
TRE31600 $451.79 10
TAR97717 $762.08 10

Transmission
Oil Pump
TAL120106 $714.81
TAL68094 $681.20 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE36936 $59.20
3) KIT, GROMMET TMX506 $17.41
4) Glow Plug TRE502079 $34.28

(1): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.
(2): Some Engines Models may use High Capacity Pump, Oil TRE65580.
(3): Saran engines may use TRE64354.
(4): Helicoidal Gears.
(5): To ESN 379968.
6): Saran Engines.
(7): Threaded Type.
(8): (m) R73604.
(9): Check application for proper usage.
(10): Check serial number for proper application.

Page 32
JOHN DEERE 6.359T

Engine Info: 6 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .000
2) = 41mm Con Rod (M): R80032, R113612

Piston (M): RE22678, RE19278 Combines 9400

Cotton Pickers 7445 7484 9930

Farm Tractors 3140C 3540 3550 4050 7200 Backhoe Loaders 710B 710C

Wheel Loaders 444D 544E 544EH 544G

Engine Series: 300 Engine Model: 6.359T

1) Engine O/H Kit TRE50783 $1,431.08
2) Engine I/F Kit TIK50783 $1,358.36 SPEC SHEET - 6059T, 6.359T Piston-Liner Kit TRE33115 $161.15 Consists of:
a) TRE19278 $107.84
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR116281 $70.79
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT22562 $2,118.73
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR28811 $67.53 (129T) TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TR57451 $11.38 x6
2) Bolt, Con Rod TR80033 $3.60 x12
3) Camshaft TR82821 $377.62 6
4) Con Rod TRE58347 $103.07
5) Kit, Piston Pin TRE63913 $27.07 x6 1) Pump, Oil TRE65580 $202.70 3
2) Oil Cooler TRE31929 $228.16
3) Rocker Arm TRE31973 $34.00 5
4) Pump, Oil Tube TR113752 $11.93
5) Cyl Hd Cap Screw TR85363 $3.42 X26 1 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54

Valve, Intake TR83071 $15.56 Std. TR89223 $19.73 0.003 TR89224 $17.44 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 4
TR79626 $13.01 0.015 4 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

1) Thermostat TAR48675 $14.80
180° F 2
2) Water Temp Sensor TRE51774 $27.68 7
3) Water Temp Sensor TRE52722 $16.59 7 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit See Chart Water Pump TAR97717 $762.08 7 Transmission Oil Pump TAL120106 $714.81 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE37503 $59.20
3) KIT, GROMMET TMX506 $17.41

(1): Replace all R78558 Cap Screws with Flanged Head Cap Screw
TR85363.
(2): Saran engines may use TRE64354.
(3): Some Engines Models may use Standard Capacity Pump, Oil TRE55343.
(4): Do not use 45 Degrees Valves with RE56545 Head.
(5): To ESN 379968.
(6): Threaded Type.
(7): Check for proper application.

Page 33
JOHN DEERE 6059T LITER DESIGNATED

Engine Info: 6 Cyl

Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .0002) = 41mm Con Rod (M): R80032

Engine Desc: Liter Designated

Piston (M): RE22678 Farm Tractors 3140C 6600 7200

Cotton Pickers 7445 7484 9930 Combines 9400

Wheel Loaders 444D 544E 544EH 544G

Backhoe Loaders 710B 710C Motor Grader 570B

Skidder 540E 540G 548E 548G

Engine Series: 300 Engine Model: 6059T

1) Engine O/H Kit TRE50783 $1,431.08
2) Engine I/F Kit TIK50783 $1,358.36 SPEC SHEET - 6059T, 6.359T Piston-Liner Kit TRE33115 $161.15 Consists of:
a) TRE19278 $107.84
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR116281 $70.79
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TAT22562 $2,118.73
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR28811 $67.53 (129T) TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TR57451 $11.38 x6
2) Bolt, Con Rod TR80033 $3.60 x12
3) Camshaft TR82821 $377.62 6
4) Con Rod TRE58347 $103.07
5) Kit, Piston Pin TRE63913 $27.07 x6 1) Pump, Oil TRE65580 $202.70 3
2) Oil Cooler TRE31929 $228.16
3) Pump, Oil Tube TR113752 $11.93
4) Cyl Hd Cap Screw TR85363 $3.42 x26 1 1) Lower Gear TAT24252 $117.41 4
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74 4
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54 4

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S
2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

1) Fuel Transfer Pump TRE42211 $56.51 TRE38009 $69.25 5
2) Thermostat TAR48675 $14.80 180° F 2
3) Water Temp Sensor TRE51774 $27.68 8
4) Water Temp Sensor TRE52722 8 Water Pump Repair Kit See Chart Water Pump TAR97708U $249.40 7
TRE16666 $728.31 8
TRE41157 $228.62 TAR92641 $523.16 8
TAR97717 $762.08 8 Transmission Oil Pump TAL120106 $714.81 8 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE38087 $77.63
3) KIT, GROMMET TMX506 $17.41
4) Glow Plug TRE502079 $34.28

(1): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.
(2): Saran engines may use TRE64534.
(3): Some Engine Models may use Standard Capacity Pump, Oil
TRE55343.
(4): Helicoidal Gears.
(5): Saran Engines.
(6): Threaded Type.
(7): (m) R73604.
(8): Check for proper application.

Page 34
JOHN DEERE 6.414D LARGE PIN

Engine Desc: Large Pin Engine Info: 6 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.62 in / 41 mm Wheel Loaders 544C Engine Model Marine Ag

Engine Series: 300 Engine Model: 6.414D

1) Engine O/H Kit TOK3694 $1,413.68
2) Engine I/F Kit TIK3694 $1,364.74 SPEC SHEET - 6068D, 6.414D Piston-Liner Kit TRE28966 $176.91 Consists of:
a) TRE28919 $88.28
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR80500 $63.25
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030 Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TRE45517 $2,102.50 1
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR28811 $67.53 (129T) TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TR57451 $11.38 x6
2) Bolt, Con Rod TR74195 $4.74 x12 4
3) Camshaft TR82821 $377.62 2
4) Kit, Piston Pin TRE63913 $27.07 x6
5) Con Rod TRE53716 $190.66 1) Pump, Oil TRE65580 $202.70
2) Rocker Arm TRE31973 $34.00
3) Cyl Hd Cap Screw TR85363 $3.42 x26 3
4) Tensioner Belt TAL110621 $99.41 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54

Valve, Intake
TR79623 $9.82 Std.
TR79628 $9.82 0.003
TR79629 $9.83 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring, Valve TR87627 $0.48

Thermostat TAR48675 $14.80 180° F 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19510 $69.50 With Impeller TRE11348 $101.78 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE37503 $59.20
3) KIT, GROMMET TMX506 $17.41

(1): Crankshaft (m) R104523.
(2): Threaded Type.
(3): From ESN 137165 The Cylinder Head Cap Screw is 4.5 in (114mm) in Length.
(4): When used on connecting rods marked R56187, torque bolts to 95 ft.lbs. Only.

Page 35
JOHN DEERE 6068D LITER DESIGNATED, LARGE PIN

Engine Info: 6 Cyl

Engine Desc: Large Pin Liter
Designated Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.62 in / 41 mm Renault Tractors
Ares 630 RX Ares 630 RZ Ares 640 RZ Ares 710 RZ Ares 720 RZ Ares 735 RZ Ares 815 RZ Ares 825 RZ Farm Tractors 6506

Engine Model Marine Ag

Engine Series: 300 Engine Model: 6068D

1) Engine O/H Kit TOK3694 $1,413.68
2) Engine I/F Kit TIK3694 $1,364.74 SPEC SHEET - 6068D, 6.414D Piston-Liner Kit TRE28966 $176.91 Consists of:
a) TRE28919 $88.28
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR80500 $63.25
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030 Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44
3) Crankshaft TRE45517 $2,102.50 3
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR28811 $67.53 (129T) TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TR57451 $11.38 x6
2) Bolt, Con Rod TR74195 $4.74 x12 5
3) Camshaft TR82821 $377.62 2
4) Kit, Piston Pin TRE63913 $27.07 x6
5) Con Rod TRE53716 $190.66 1) Pump, Oil TRE65580 $202.70
2) Cyl Hd Cap Screw TR85363 $3.42 X26 4
3) Tensioner Belt TAL110621 $99.41 1) Lower Gear TAT24252 $117.41 1
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74 1
4) Upper Bushing TT20034 $5.89
5) Cam. Follower1 TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54 1

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S
2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

Thermostat TRE64354 $10.66 180° F 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit Without Impeller TRE19510 $69.50 With Impeller TRE11348 $101.78 Water Pump TRE41157 $228.62 TRE16666 $728.31 6 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE38087 $77.63
3) KIT, GROMMET TMX506 $17.41
4) Glow Plug TRE502079 $34.28

(1): Helicoidal Gears.
(2): Threaded Type.
(3): Crankshaft (m) R104523.
(4): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.
(5): When used on connecting rods marked R56187, torque bolts to 95 ft.lbs. Only.
(6): Check application for proper usage.

Page 36
JOHN DEERE 6.414T

Engine Info: 6 Cyl Engine Dimensions: Bore:
4.19 in / 106.5 mm
Pin Ø: 1.62 in / 41 mm Please see page 436 for a complete list of equipment models.

Engine Series: 300 Engine Model: 6.414T

1) Engine O/H Kit TOK61614 $1,413.68
2) Engine I/F Kit TIK61614 $1,358.61 SPEC SHEET - 6068T, 6.414T Piston-Liner Kit TRE53073 $183.95 Consists of:
a) TRE48469 $92.70
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR80500 $63.25
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030 Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TRE45517 $2,102.50 3
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR28811 $67.53 (129T) TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TR57451 $11.38 x6
2) Bolt, Con Rod TR74195 $4.74 x12 5
3) Camshaft TR82821 $377.62 2
4) Kit, Piston Pin TRE63913 $27.07 x6
5) Con Rod TRE53716 $190.66 1) Pump, Oil TRE65580 $202.70
2) Rocker Arm TRE31973 $34.00
3) Cyl Hd Cap Screw TR85363 $3.42 x26 4
4) Tensioner Belt TAL110621 $99.41 1) Lower Gear TAT24252 $117.41
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54

Valve, Intake TR83071 $15.56 Std. TR89223 $19.73 0.003 TR89224 $17.44 0.015 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015 1) Insert, Valve In TR73064 $12.02 Std.
2) Insert, Valve Ex TR51734 $12.96 Std. 1) Cap, Valve TT20129 $2.77
2) Lock, Valve TT20077 $0.97 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE11410 $12.79
3) O'ring Valve TR87627 $0.48

1) Thermostat
TAR48675 $14.80
180° F
2) Water Temp Sensor TRE51774 $27.68 6 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit See Chart 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE37503 $59.20
3) KIT, GROMMET TMX506 $17.41

(1): Do not use 45 Degree Valves with RE56545 Head.
(2): Threaded Type.
(3): Crankshaft (m) R104523.
(4): From ESN 137165 The Cylinder Head Cap Screw is 4.5 in (114mm) in Length.
(5): When used on connecting rods marked R56187, torque bolts to 95 ft.lbs. Only.

Page 37
JOHN DEERE 6068T LITER DESIGNATED

Engine Desc: Liter Designated
Engine Info: 6 Cyl Engine Dimensions: Bore: 4.19 in /106.5 mm
Pin Ø: 1.62 in /41 mm Please see page 437 for a complete list of equipment models.

Engine Series: 300 Engine Model: 6068T

1) Engine O/H Kit TOK61614 $1,413.68
2) Engine I/F Kit TIK61614 $1,358.61 SPEC SHEET - 6068T, 6.414T Piston-Liner Kit TRE53073 $183.95 Consists of:
a) TRE48469 $92.70
b) TRE66820 $26.88
c) TR124230 $18.50
d) TR80500 $63.25
e) TAR65507 $7.24
f) TR54114 $1.84 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030
Use 6 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030
Use 1 Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030 Use 6

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $30.44 1
3) Crankshaft TRE45517 $2,102.50 3
4) Crankshaft, Gear TT20094 $75.08
5) Ring Gear TR28811 $67.53 (129T) TR114282 $39.11 (142T)
6) Sleeve, Front TR81989 $33.02
7) Packing, Sleeve TH35244 $0.13 1) O/H Gasket Set TRE501580 $175.86
2) Head Gasket Set TRE38852 $106.33
3) Head Gasket TR114157 $38.37
4) Oil Pan Gasket TR97344 $30.51
5) Rocker Cover Gsk TR75728 $24.84
6) Gasket, Turbo Mount TR89879 $7.48
7) Gasket Thermostat Housing TT20219 $0.75 1) Bush, Con Rod TR57451 $11.38 x6
2) Bolt, Con Rod TR74195 $4.74 x12 5
3) Camshaft TR82821 $377.62 2
4) Kit, Piston Pin TRE63913 $27.07 x6 1) Pump, Oil TRE65580 $202.70
2) Cyl Hd Cap Screw TR85363 $3.42 x26 4
3) Tensioner Belt TAL110621 $99.41 1) Lower Gear TAT2425 $104.82 1
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $147.74 1
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $11.56 x12
6) Cam. Gear TT20070 $114.54 1

Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015 Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015 1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S
2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S 1) Seal, Valve TRE31617 $3.06
2) Lock, Valve TR91889 $0.51 1) Spring, Valve TR26125 $2.91
2) Rotator, Valve TRE60005 $17.28

1) Thermostat TRE33705 $10.66
180° F
2) Water Temp Sensor TRE51774 $27.68 6
3) Water Temp Sensor TRE52722 $16.59 6
4) Thermostat Cover Gsk TT20215 $0.84 1) Fuel Transfer Pump TRE42211 $56.51
2) Fuel Pump Gasket TR27285 $1.31 Water Pump Repair Kit See Chart Water Pump TRE41157 $228.62 6
TRE16666 $728.31 6 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TRE38087 $77.63
3) KIT, GROMMET TMX506 $17.41
4) Glow Plug TRE502079 $34.28

(1): Helicoidal Gears.
(2): Threaded Type.
(3): Crankshaft (m) R104523.
(4): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.
(5): When used on connecting rods marked R56187, torque bolts to 95 ft.lbs. Only.

Page 38
JOHN DEERE 4.270 TO ESN 280,000 SEE BLOCK

Engine Data: To ESN 280,000

Engine Info: 4 Cyl Engine Dimensions: Bore: 4.25 in / 108 mm Pin Ø: 1.50 in / 38 mm Block (M): R46350, R46430, R40910

Con Rod (M): R26047, R58880, R66923 Farm Tractors 3020

Backhoe Loaders 500 500A

Engine Series: 400 Engine Model: 4.270

1) Engine O/H Kit TRG17898 $1,013.04
2)Engine I/F Kit TIK17898 $914.20 SPEC SHEET - 4.270 Piston-Liner Kit TRE23170 $205.33 Consists of:
a) TRE23172 $112.91
b) TAR55630 $34.68
c) TR44161
d) TR40615 $78.92
e) TAR65507 $7.24
f) TH80753 $1.20 Main Bearing TAR74814 $22.68 Std. TAR74816 $22.68 0.010 TAR74817 $22.68 0.020 TAR74818 $22.68 0.030
Use 4 Thrust Bearing TAR77748 $35.47 Std. TAR77750 $35.47 0.010 TAR77751 $35.47 0.020 TAR77752 $35.47 0.030
Use 1 Thrust Washer TAR77747 $20.21 Std. TAR77753 $30.41 0.007
Use 3, Order Qty: 1 Con Rod Bearing TAR45723 $15.63 Std. TAR46396 $15.63 0.010 TAR46397 $15.63 0.020 TAR46398 $15.63 0.030
Use 4

1) Front Seal TAR49025 $15.72
2) Rear Seal TRE520036 $41.64
3) Crankshaft TAR40485 $2,799.53 1
4) Crankshaft, Gear TR26049
5) Ring Gear TR28811 $67.53 (129T) 1) O/H Gasket Set TAR53033 $114.55
2) Head Gasket Set TAR53032 $89.62
3) Head Gasket TR45616 $52.48
4) Oil Pan Gasket TR71917 $37.71
5) Rear Cover Gasket TR26058 $9.38
6) Exhaust Manifold Gsk TR83020 $3.92 1) Bush, Con Rod TR30939 $7.19 x4
2) Bolt, Con Rod TR66452 $5.99 x8
3) Bushing, Cam TR46903 $8.09 x3
4) Con Rod TAR70910 $147.97 1) Cam Follower TR52773 $10.44 x8
2) Plug, Camshaft TR26115 $7.73

Valve, Intake TR26124 $14.36 Std. 2
TR44174 $13.60 Std. 3 Valve, Exhaust TR26123 $16.08 Std. 2
TR44175 $16.25 Std. 3 1) Insert, Valve In TR43680 $9.19 Std.
2) Insert, Valve Ex TR43681 $12.17 Std. 1) Lock, Valve TB367R $0.90 x16 1) Spring, Valve TR26125 $2.91
2) Guide, Valve TR28654 $7.11
3) O'ring, Valve TR87627 $0.48

Thermostat TR36846 $14.54 180° F Fuel Transfer Pump TAR53567 $91.67 Water Pump Repair Kit See Chart 1) Seal, Injector TR60746 $0.38 TR48000 $1.06
2) Injector, Pencil TAR50781 $78.69 Water Pump TAR45332 $153.41

(1): New style crankshaft. To adapt to old style, the center hole in the flywheel needs to be enlarged to 2.835 in. (72.0009 mm).
(2): To ESN 157,001.
(3): ESN 157,002 – 280,000.

More coming

Top of Page

HOME

Cummins®	B & C Series • ISB • QSB • QSC • 3.3 Liters • 3.9 Liters • 4.5 Liters • 5.9 Liters • 6.7 Liters • 8.3 Liters
John Deere®	3.152 • 3.164 • 3.179 • 4.202 • 4.219 • 4.239 • 4.270 • 4.276 • 6.101 • 6.303 • 6.329 • 6.359 • 6.404 • 6.414 • 6.466 6.531 • 6.619 • 3016 • 3029 • 4020 • 4024 • 4033 • 4039 • 4045 • 5030 • 6076 •6068 • 6081 • 6090 • 6125•6135
Caterpillar	3013C, 3014, 3024C, 3024C/T, 3034C, 3034T, 3044C, 3044C/T, 3046, 3054, 3054T, 3054B, 3054C/E, 3054E, 3054C/E, 3056, 3056T, 3056E, 3064T, 3066, C2.2, C3.3, C3.3T, C3.8, C4.2, C4.4B Acert, C4.4T/TA, C6.4, C6.6, C6.6 Acert, C7.1, C7.1 ACERT
Perkins®	3.152 • 4.108 • 4.203 • 4.212 • 4.236 • 4.248 • 4.318 • 6.354 • 104-22 • 403C-15 • 403D-15 • 404C-22 • 404D-22 404F-22 • 704-30 • 804C-33 • 804D-33 • 1004.40 • 1004.42 • 1006.60 • 1103 • 1104 • 1106C • 1106D • 1204E • 1206E • 1206F
Yanmar®	3TNE84 • 3TNE84T • 3TNE88 • 3TNV70 • 3TNV76 • 3TNV84 • 3TNV88 • 4TNE106D • 4TNE106T • 4TNE84 4TNE86 • 4TNE88 • 4TNE92 • 4TNE94 • 4TNE98 • 4TNV106 • 4TNV106T • 4TNV84 • 4TNV84T • 4TNV86 • 4TNV88 • 4TNV94L • 4TNV98 • 4TNV98C • 4TNV98CT • 4TNV98T • TK486 • TK486V
Mitsubishi®	S4K • S4S • S4S DT • S6K • S6S • S6S D • S6S DT
Shibaura®	N4LDI • N843 • N843L • N844 • N844L • N844L-D • N844L-F • N844LT • N844LT-D • N844LT-F • N844LTA-D • N844T
Komatsu®	3D70E • 3D76E • 3D84E • 3D88E • 4D84E • 4D88E • 4D94E • 4D94LE • 4D95LE • 4D98E • 4D102 • 4D106 4D107 • 6D102 • 6D107 • 6D114 • S3D84E • S4D95LE • S4D106
Kubota®	D902 • D905 • D1105 • D1703 • D1803 • V1505 • V1702 • V2003 • V2203 • V2403 • V2607 • V3300 • V3307 V3307-CR • V3800 • V3800-CR
IH/Navistar®	DT360 • DT414 • DT436 • DT437 • DT466
Isuzu®	3CA1 • 3CB1 • 3CD1 • 3CE1 • 4GC1T
Skid Steer Loaders	Various Makes & Models

John Deere	Page	John Deere	Page
John Deere 3.152 O'rings on liner	2	John Deere 3.152 O'rings on Block	3
John Deere 3.164 Small Pin, O'rings on Liner	4	John Deere 3.164 Small Pin, O'rings on Block	5
John Deere 3.164 Large Pin, O'rings on Block	6	John Deere 3.179D	7
John Deere 3029D Liter Designated	8	John Deere 3.179T	9
John Deere 3029T Liter Designated	10	John Deere 4.202 O'rings on liner	11
John Deere 4.202 O'rings on block	12	John Deere 4.219 Small Pin, O'rings on Liner	13
John Deere 4.219 Small Pin, O'rings on Block	14	John Deere 4.219 Large Pin, O'rings on Block	15
John Deere 4.239D	16	John Deere 4039D Liter Designated	17
John Deere 4.239T	18	John Deere 4039T Liter Designated	19
John Deere 4.276D Small Pin	20	John Deere 4.276D Large Pin	21
John Deere 4045D Liter Designated	22	John Deere 4.276T	23
John Deere 4045T Liter Designated	24	John Deere 6.303 O'rings on Liner	25
John Deere 6.303 O'rings on Block	26	John Deere 6.329 Small Pin, O'rings on Liner	27
John Deere 6.329 Small Pin, O'rings on Block	28	John Deere 6.329 Large Pin, O'rings on Block	29
John Deere 6.359D	30	John Deere 6059D Liter Designated	31
John Deere 6.359T	32	John Deere 6059T Liter Designated	33
John Deere 6.414D Large Pin	34	John Deere 6068D Liter Designated, Large Pin	35
John Deere 6.414T	36	John Deere 6068T Liter Designated	37
John Deere 4.270 To ESN 280,000 See Block	38	John Deere 4.270 To ESN 280,000	39
John Deere 4.270 To ESN 280,000 Early Power Booster	40	John Deere 4.270 From ESN 280,001	41
John Deere 6.404D To ESN 214,999 See Block	42	John Deere 6.404D To ESN 214,999	43
John Deere 6.404D To ESN 214,999 Early Power Boost	44	John Deere 6.404D ESN 215,000 – 335,845	45
John Deere 6.404D From ESN 335,846	46	John Deere 6.404T/A To ESN 335,845	47
John Deere 6.404T/A From ESN 335,846	48	John Deere 6.466D	49
John Deere 6.466A/T Con Rod (m): R57303, R67320	50	John Deere 6.466A/T Con Rod (m) R71074	51
John Deere 6.466A ESN 233,593-317,858	52	John Deere 6076 T/A/H Low Ring Piston	53
John Deere 6076 T/A/H High Ring Piston	54	John Deere 6.531D See Con. Rod (m)	55
John Deere 6.531T See Con. Rod (m)	56	John Deere 6.531A See Con. Rod (m)	57
John Deere 6.619A/T Early	58	John Deere 6.619A/T Mid	59
John Deere 6.619A/T Late	60	John Deere 6.101A/T TO ESN 499,999	61
John Deere 3TNE84 84mm Bore Non Turbo	62	John Deere 4TNE84 84mm Bore Non Turbo	63
John Deere 4TNE84T 84mm Bore Turbo	64	John Deere 3TNE88 88mm Bore Non Turbo	65
John Deere 4TNE88 88mm Bore Non Turbo	66	John Deere 3TNV84 84mm Bore Non Turbo & Turbo	67
John Deere 4TNV84 84mm Bore Non Turbo	68	John Deere 4TNV84T 84mm Bore Turbo	69
John Deere 3TNV88 88mm Bore Non Turbo	70	John Deere 4TNV88 88mm Bore Non Turbo	71
John Deere 4TNV98 98mm Bore Non Turbo Direct Injection	72	John Deere 4TNV98T 98mm Bore Turbo Direct Injection	73
John Deere 3029 2.9D Piston (m) RE61467	74	John Deere 3029 2.9D/T Piston (m) RE520573	75
John Deere 3029 2.9T Piston (m) RE61270	76	John Deere 3029 2.9T Piston (m) RE500211	77
John Deere 4024TL, TIER 3, PISTON (M) RE522094	78	John Deere 4024TT Early, TIER 2, PISTON (M) RE516347	79
John Deere 4024TT Late, TIER 2 & 3, PISTON (M) RE526785	80	John Deere 4024HF, TIER 3, PISTON (M) RE527622	81
John Deere 4045 4.5T/H Piston (m) RE55512/RE505102	82	John Deere 4045 4.5T/H Piston (m) RE527039 Tier 2 & Tier 3	83
John Deere 4045 4.5T/H Piston (m) RE521616 Tier 2 & Tier 3	84	John Deere 4045 4.5T/H Piston (m) RE515037 Tier 2 & Tier 3	85
John Deere 4045 4.5T/H Piston (m) RE507758 Tier 2 & Tier 3	86	John Deere 4045 4.5T/H Piston (m) RE515037 Tier 2 & Tier 3 (2)	87
John Deere 4045 4.5T/H Piston (m) RE545770 Tier 2 & Tier 3	88	John Deere 4045D 4.5D Piston (m) RE59279/RE505101	89
John Deere 4045T 4.5T Piston (m) RE59277/RE505100	90	John Deere 4045 4.5T/H Piston (m) RE544601 Interim Tier 4	91
John Deere 4045 4.5T/H Piston (m) RE544607 Interim Tier 4	92	John Deere 4045 4.5T/H Piston (m) RE551101 Tier 4 Final	93
John Deere 4045 4.5T/H Piston (m) RE570485 Tier 4 Final	94	John Deere 5030TT Late, TIER 2 & 3, PISTON (M) RE526785	95
John Deere 5030TT Early, TIER 2, PISTON (M) RE516347	96	John Deere 5030TL, TIER 3, PISTON (M) RE522094	97
John Deere 5030HF, TIER 3, PISTON (M) RE527622	98	John Deere 6068 6.8T/H Piston (m) RE55512 / RE505102	99
John Deere 6068 6.8T/H Piston (m) RE521616 Tier 2 & Tier 3	100	John Deere 6068 6.8T/H Piston (m) RE515037 Tier 2 & Tier 3	101
John Deere 6068 6.8T/H Piston (m) RE507758 Tier 2 & Tier 3	102	John Deere 6068 6.8T/H Piston (m) RE527039 Tier 2 & Tier 3 (2)	103
John Deere 6068 6.8T/H Piston (m) RE545770 Tier 2 & Tier 3 1	04	John Deere 6068 6.8L Piston (m) RE544601 Interim Tier 4	105
John Deere 6068 6.8L Piston (m) RE553821 Tier 4 Final	106	John Deere 6068 6.8L Piston (m) RE544607 Interim Tier 4	107
John Deere 6068D 6.8D Piston (m) RE59279/RE505101	108	John Deere 6068T 6.8T Piston (m) RE59277 / RE505100	109
John Deere 6081 High Compression Piston, to ESN 199,999	110	John Deere 6081 Low Compression Piston, to ESN 199,999 1	11
John Deere 6081 Forged Steel Piston, from ESN 200,000 and up	112	John Deere PowerTech 6090 9.0L Tier 2 & 3, Piston # RE529264	113
John Deere PowerTech 6090 9.0L Tier 4, Piston # RE555132	114	John Deere PowerTech 6090 9.0L Tier 4, Piston # DZ102298	115

1) Engine O/H Kit TOK3481 $810.75 2) Engine I/F Kit TIK3481 $726.80 SPEC SHEET - 3.152 JOHN DEERE \|\|	Piston-Liner Kit TPLK481 $173.99 Consists of: a) TT23481 $70.48 b) TAR70633 $33.05 c) TT23482 $12.50 d) TAR51902 $66.44 e) TR51112 $1.06	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 3














1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TAT18031 $963.03 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE38570 $120.89 2) Head Gasket Set TRE38848 $75.17 3) Head Gasket TR98460 $32.84 4) Oil Pan Gasket TR97341 $10.88 5) Rocker Cover Gsk TR75729 $16.07 6) Timing Cover Gasket TT20273 $2.62 7) Gasket Thermostat Housing TT20219 $0.75	1) Bush, Con Rod TT23471 $9.57 x3 2) Bolt, Con Rod TR74194 $2.78 x6 4 3) Camshaft Kit TRE55900 $418.14 5 4) Con Rod TAT18005 $87.01	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54985 5) Pump, Oil Tube TR113752 $11.93 6) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x6 6) Cam. Gear TT20070 $114.54 7) Camshaft Kit TRE55900 $418.14 5
Valve, Intake ; Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TRE33705 $10.66 180° F 2) Thermostat Cover TT23620 $15.12 3) Thermostat Cover Gsk TT20215 $0.84 2	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 6 With Impeller TRE62658 $75.66 6 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Injector, Pencil TAR89564 $59.20 2) Kit, Grommet TMX504 $11.61 3) Cap TAT27622 $6.18 TAR85618 $8.44 4) Washer TT29539 $0.46 5) Tube Nut TR51937 $5.77	Seal, Injector TR60746 $0.38 TR48000 $1.06
(1): Do not use with Flywheel Housing (m) T20300, T22991. (2): Do not use with Housing (m) R54096, R70741, R74549. (3): Conversion Kit TMX386: Available Consists of: TT31306, X1 Nipple TR99802, X2 Hose. (4): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410. (5): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957, and RE522311. (6): See the Water Pump Identification Chart to make sure these part numbers are correct. You will need the water pump casting number and will need to know if you have a stamped steel pulley or a cast iron pulley.

Engine Desc: From ESN 154,766 Engine Data: O-rings on Block	Engine Dimensions: Bore: 3.86 in / 98 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm	Block (M): R53240, R55100, R72967, T32339 Con Rod (M): T20007, R81410	Piston (M): AR87736, AR90550 Farm Tractors 820 830 1020 1030	Backhoe Loaders 300 300A 300B 301 301A Crawler Dozers 350A 350B Forklifts 380
Engine Series: 300 Engine Model: 3.152
1) Engine O/H Kit TOK3591 $758.31 2) Engine I/F Kit TIK3591 $692.72 SPEC SHEET - 3.152 JOHN DEERE	Piston-Liner Kit TAR71591 $162.02 Consists of: a) TT23481 $70.48 b) TAR70633 $33.05 c) TT23482 $12.50 d) TT32340 $60.49 e) TAR71617 $9.12 f) TR51112 $1.06	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 0.030 Use 3	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 3















1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TAT18031 $963.03 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE38570 $120.89 2) Head Gasket Set TRE38848 $75.17 3) Head Gasket TR98460 $32.84 4) Oil Pan Gasket TR97341 $10.88 5) Rocker Cover Gsk TR75729 $16.07 6) Timing Cover Gasket TT20273 $2.62 7) Gasket Thermostat Housing TT20219 $0.75	1) Bush, Con Rod TT23471 $9.57 x3 2) Bolt, Con Rod TR74194 $2.78 x6 4 3) Camshaft Kit TRE55900 $418.14 5 4) Con Rod TAT18005 $87.01	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54985 5) Pump, Oil Tube TR113752 $11.93 6) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x6 6) Cam. Gear TT20070 $114.54 7) Camshaft Kit TRE55900 $418.14 5
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TRE33705 $10.66 180° F 2 2) Thermostat Cover TT23620 $15.12 3) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 6 With Impeller TRE62658 $75.66 6 Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Injector, Pencil TAR89564 $59.20 2) Kit, Grommet TMX504 $11.61 3) Cap TAT27622 $6.18 TAR85618 $8.44 4) Washer TT29539 $0.46 5) Tube Nut TR51937 $5.77	Seal, Injector TR60746 $0.38 TR48000 $1.06
(1): Do not use with Flywheel Housing (m) T20300, T22991. (2): Do not use with Housing (m) R54096, R70741, R74549. (3): Conversion Kit TMX386: Available Consists of: TT31306, X1 Nipple TR99802, X2 Hose. (4): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410. (5): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957, and RE522311. (6): See the Water Pump Identification Chart to make sure these part numbers are correct. You will need the water pump casting number and will need to know if you have a stamped steel pulley or a cast iron pulley.

Engine Desc: To ESN 179,601 Engine Data: Small Pin, O'rings on Liner	Engine Info: 3 Cyl	Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm	Con Rod (M): T20007, R81410 Piston (M): AR78310	Farm Tractors 1520 Backhoe Loaders 302 302A
Engine Series: 300 Engine Model: 3.164
1) Engine O/H Kitt TOK3310 $834.43 2) Engine I/F Kit TIK3310 $742.85 SPEC SHEET - 3.164	Piston-Liner Kit TPLK310 $182.40 Consists of: a) TAR78310 $85.39 b) TAR55759 $26.30 c) TT26149 $5.47 d) TAR51903 $67.96 e) TR51112 $1.06	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 3














1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT18031 $963.03 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE501578 $113.10 2) Head Gasket Set TRE38850 $43.83 3) Head Gasket TR97356 $23.74 4) Oil Pan Gasket TR97341 $10.88 5) Rocker Cover Gsk TR75729 $16.07	1) Bush, Con Rod TT23471 $9.57 x3 2) Bolt, Con Rod TR74194 $2.78 x6 3 3) Camshaft Kit TRE55900 $418.14 5 4) Con Rod TAT18005 $87.01	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 2 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54985 5) Pump, Oil Tube TR113752 $11.93 6) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x6 6) Cam. Gear TT20070 $114.54 7) Camshaft Kit TRE55900 $418.14 5
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TRE33705 $10.66 180° F 1 2) Thermostat Cover TT23620 $15.12 3) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 6 With Impeller TRE62658 $75.66 6	1) Water Pump TAT27018 $299.99 4 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX504 $11.61 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77
(1): Do not use with Housing (m) R54096, R70741, R74549. (2): Conversion Kit TMX386: Available Consists of: TT31306, x1 Nipple TR99802, x2 Hose. (3): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410. (4): (m) R48997, (m) R51039. (5): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957, and RE522311. (6): See the Water Pump Identification Chart to make sure these part numbers are correct. You will need the water pump casting number and will need to know if you have a stamped steel pulley or a cast iron pulley.

Engine Desc: From ESN 179,602 Engine Data: Large Pin, O'rings on Block	Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm	Block (M): R55100, R72967, R72965, R80408 Con Rod (M): RE19733 (SUB FOR AT18005)	Piston (M): AR77762 Farm Tractors 1530 2040 2330 Backhoe Loaders 301A 302 302A 310	Crawler Dozers 350B 350C 350D
Engine Series: 300 Engine Model: 3.164
1) Engine O/H Kit TOK3041 $781.91 2) Engine I/F Kit TIK3041 $638.45 SPEC SHEET - 3.164	Piston-Liner Kit TAR78041 $151.32 Consists of: a) TAR77762 $77.10 b) TAR55759 $26.30 c) TR125754 $12.08 d) TR116463 $64.39 e) TAR71618 $7.95 f) TM41029 $1.07	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 3












1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT18031 $963.03 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T	1) O/H Gasket Set TRE501578 $113.10 2)Head Gasket Set TRE38850 $43.83 3) Head Gasket TR97356 $23.74 4) Oil Pan Gasket TR97341 $10.88 5) Rocker Cover Gsk TR75729 $16.07	1) Bush, Con Rod TR55647 $8.00 x3 2) Bolt, Con Rod TR74194 $2.78 x6 3 3) Camshaft Kit TRE55900 $418.14 5 4) Con Rod TRE16495 $92.02	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 2 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54985 5) Pump, Oil Tube TR113752 $11.93 6) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x6 6) Cam. Gear TT20070 $114.54 7) Camshaft Kit TRE55900 $418.14 5
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TRE33705 $10.66 180° F 1 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 6 4) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair TRE19507 $60.74 7 With Impeller TRE62658 $75.66 7	1) Water Pump TAT27018 $299.99 4 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 Transmission Oil Pump TAL120106 $714.81 4	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 Pump TAL1201064 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX504 $11.61 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77
(1): Do not use with Housing (m) R54096, R70741, R74549. (2): Conversion Kit TMX386: Available Consists of: TT31306 $10.15 x1 Nipple TR99802, x2 Hose. (3): For Connecting Rods RE16495 and RE21076 Use Connecting Rod Bolt TR80033. (4): (m) R48997, (m) R51039. (5): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957, and RE522311. (6): Check for Proper Application. (7): See the Water Pump Identification Chart to make sure these part numbers are correct. You will need the water pump casting number and will need to know if you have a stamped steel pulley or a cast iron pulley.

Engine Info: 3 Cyl	Engine Dimensions: Bore: 4.19 in / 106 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm	Con Rod (M): R80034 Piston (M): RE24458 , RE24539, RE30250	Farm Tractors 1140 1140 1350 1550 1630 1750 1850 2040 2150 2155 2240 5000	Crawler Dozers 350D 355D Ditch Witch JT2320 Directional Boring System
Engine Series: 300 Engine Model: 3.179D
1) Engine O/H Kit TRE47653 $771.46 2) Engine I/F Kit TIK47653 $713.89 SPEC SHEET - 3.179D	Piston-Liner Kit TRE30250 $161.15 Consists of: a) TRE19282 $107.84 b) TRE66820 $26.88 c) TR125754 $12.08 d) TR116281 $70.79 e) TAR65507 $7.24 f) TM41029 $1.07	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 3













1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TAT18031 $963.03 1 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501578 $113.10 2) Head Gasket Set TRE38850 $43.83 3) Head Gasket TR97356 $23.74 4) Oil Pan Gasket TR97341 $10.88 5) Rocker Cover Gsk TR75729 $16.07	1) Bush, Con Rod CTR55647 $8.00 x3 2) Bolt, Con Rod TR80033 $3.60 x6 3) Camshaft Kit TRE55900 $418.14 8 4) Con Rod TRE16495 $92.02	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE3192 4 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54985 5) Pump, Oil Tube TR113752 $11.93 6) Cyl Hd Cap Screw TR85363 $3.42 x14 3 Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x6 6) Cam. Gear TT20070 $114.54 7) Camshaft Kit TRE55900 $418.14 8 8) Camshaft TR106957 $327.73 8
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR8762
1) Thermostat TRE33705 $10.66 180° F 2 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 7 4) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66	1) Water Pump TAR97708U $249.40 5 TRE60489 $227.48 6 TAR92641 $523.16 7 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92 Transmission Oil Pump TAL120106 $714.81 TAL68094 $681.20	1) Seal, Injector Pump TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX504 $11.61 \|4) Glow Plug TRE502079 $34.28 5) Cap TAT27622 $6.18 TAR85618 $8.44 6) Washer TT29539 $0.46 7) Tube Nut TR51937 $5.77
(1): Crankshaft (m) T23516 (36 mm / 1.37” Snout.) This engine may use TRE50979, (60 mm / 2.36” Snout) (m) R91834. (2): Do not use with Housing (m) R54096, R70741, R74549. For Saran Repower Engines use TRE64354. (3): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (4): Use on engines ESN 794193, after this ESN use TRE61767. (5): (m) R73604. (6): (m) R78286, (m) R70437, (m) R100812, (m) R127337, (m) R127918, (m) R55164. (7): Check your application for proper usage. (8): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957, and RE522311.

Engine Desc: Liter Designated Engine Info: 3 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm	Con Rod (M): R51727, R80034 Piston (M): RE30250	Farm Tractors 5200 5300 5400	Skid Steers 240 240 Series
Engine Series: 300 Engine Model: 3029D
1)Engine O/H Kit TRE47653 $771.46 2) Engine I/F Kit TIK47653 $713.89 SPEC SHEET - 3029D	Piston-Liner Kit TRE30250 $161.15 Consists of: a) TRE19282 $107.84 b) TRE66820 $26.88 c) TR125754 $12.08 d) TR116281 $70.79 e) TAR65507 $7.24 f) TM41029 $1.07	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 3
















1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TRE521348 $1,330.74 5 4) Crankshaft, Gear TT20094 $75.08 3 $67.03 5) Ring Gear TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501578 $113.10 2)Head Gasket Set TRE38850 $43.83 3) Head Gasket TR97356 $23.74 4) Oil Pan Gasket TR97341 $10.88 5) Rocker Cover Gsk TR75729 $16.07 2 $16.07 TR106796 $10.02 1	1) Bush, Con Rod TR55647 $8.00 x3 2) Bolt, Con Rod TR80033 $3.60 x6 3) Camshaft Kit TRE55900 $418.14 9 4) Con Rod TRE16495 $92.02	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE61767 $211.92 3) Pump, Oil Tube TR113752 $11.93 4) Cyl Hd Cap Screw TR85363 $3.42 x14 4 5) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 3 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 3 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x6 6) Cam. Gear TT20070 $114.54 3 7) Camshaft Kit TRE55900 $418.14 9 8) Camshaft TR106957 $327.73 9
Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015	Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015	1) Insert, Valve In TR98063 $5.96 O/S TR98335 $30.57 O/S 2) Insert, Valve Ex TR51734 $12.96 Std. TR93910 $11.22 O/S	1) Seal, Valve TRE31617 $3.06 2) Lock, Valve TR91889 $0.51	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE60005 $17.28
1) Thermostat TRE64354 $10.66 180° F 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 8 4) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31 3) Fuel Filter Base with Prime TRE67225 $159.99	Water Pump Repair Kit Without Impeller TRE19507 $60.74 10 With Impeller TRE62658 $75.66 10	1) Water Pump TAR97708U $249.40 6 TRE60489 $227.48 7 TAR92641 $523.16 8 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE36936 $59.20 3) Kit, Grommet TMX504 $11.61
(1): Not included in Gasket Set. Used in Saran Engines (Order Separately). (2): Reusable. (3): Helicoidal Gears. (4): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (5): Kit contains TT20094 $75.08 helical gear to convert to a TRE50979, Crankshaft. (6): (m) R73604. (7): m) R100812, (m) R127337, (m) R127918, (m) R55164. (8): Check your application for proper usage. (9): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957, and RE522311. (10): See the Water Pump Identification Chart to make sure these part numbers are correct. You will need the water pump casting number and will need to know if you have a stamped steel pulley or a cast iron pulley.

Engine Info: 3 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .0002) = 41mm	Con Rod (M): R80032 Piston (M): RE22678	Farm Tractors 2355NCS 2355NTSS	Ditch Witch JT2321 Directional Boring System
Engine Series: 300 Engine Model: 3.179T
1) Engine O/H Kit TOK3115 $781.72 2) Engine I/F Kit TIK3115 $679.31 SPEC SHEET - 3.179T, 3029T	Piston-Liner Kit TRE33115 $161.15 Consists of: a) TRE19278 $107.84 b) TRE66820 $26.88 c) TR124230 $18.50 d) TR116281 $70.79 e) TAR65507 $7.24 f) TR54114 $1.84	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 3
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TAT18031 $963.03 3 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501578 $113.10 2) Head Gasket Set TRE38850 $43.83 3) Head Gasket TR97356 $23.74 4) Oil Pan Gasket TR97341 $10.88 5) Rocker Cover Gsk TR75729 $16.07	1) Bush, Con Rod TR57451 $11.38 x3 2) Bolt, Con Rod TR80033 $3.60 x6 3) Con Rod TRE58347 $103.07 4) Kit, Piston Pin TRE63913 $27.07 x3	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 4 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54985 5) Pump, Oil Tube TR113752 $11.93 6) Cyl Hd Cap Screw TR85363 $3.42 x14 2 7) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x6 6) Cam. Gear TT20070 $114.54 7) Camshaft Kit TRE55900 $418.14 8 8) Camshaft TR106957 $327.73 8
Valve, Intake TR83071 $15.56 Std. TR89223 $19.73 0.003 TR89224 $17.44 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TRE33705 $10.66 180° F 1 2) Thermostat Cover TT23620 $15.12 3) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 9 With Impeller TRE62658 $75.66 9	1) Water Pump TAR97708U $249.40 5 TRE60489 $227.48 6 TAR92641 $523.16 7 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE37503 $59.20 3) KIT, GROMMET TMX504 $11.61 4) Glow Plug TRE502079 $34.28
(1): Do not use with Housing (m) R54096, R70741, R74549. For Saran Repower Engines use TRE64354. (2): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (3): Crankshaft (m) T23516 (36 mm / 1.37” Snout.) This engine may use TRE50979, (60 mm / 2.36” Snout) (m) R91834. (4): Use on engines ESN 794193, after this ESN use TRE61767. (5): (m) R73604. (6): (m) R100812, (m) R127337, (m) R127918, (m) R55164. (7): Check your application for proper usage. (8): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957, and RE522311. (9): See the Water Pump Identification Chart to make sure these part numbers are correct. You will need the water pump casting number and will need to know if you have a stamped steel pulley or a cast iron pulley.

Engine Desc: Liter Designated Engine Info: 3 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .000 2)= 41mm	Con Rod (M): R80032, R58979, R113612 Piston (M): RE48368	Farm Tractors 5500 Skid Steers 250 250 Series II 260 260 Series II 8875	Engine Model 3029DLV51 3029DLV52 3029DLV53 3029DLV55 3029DLV56 3029DLV57 3029TLV52 Ditch Witch JT2321 Directional Boring System
Engine Series: 300 Engine Model: 3029T
1) Engine O/H Kit TOK3115 $781.72 2) Engine I/F Kit TIK3115 $679.31 SPEC SHEET - 3.179T, 3029T	Piston-Liner Kit TRE33115 $161.15 Consists of: a) TRE19278 $107.84 b) TRE66820 $26.88 c) TR124230 $18.50 d) TR116281 $70.79 e) TAR65507 $7.24 f) TR54114 $1.84	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 3
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TRE521348 $1,330.74 5 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501578 $113.10 2)Head Gasket Set TRE38850 $43.83 3) Head Gasket TR97356 $23.74 4) Oil Pan Gasket TR97341 $10.88 5) Rocker Cover Gsk TR75729 $16.07 2 TR106796 $10.02 1	1) Bush, Con Rod TR57451 $11.38 x3 2) Bolt, Con Rod TR80033 $3.60 x6 3) Con Rod TRE58347 $103.07 4) Kit, Piston Pin TRE63913 $27.07 x3	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE61767 $211.92 3) Pump, Oil Tube TR113752 $11.93 4) Cyl Hd Cap Screw TR85363 $3.42 x14 4 5) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 3 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 3 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x6 6) Cam. Gear TT20070 $114.54 3 7) Camshaft Kit TRE55900 $418.14 9 8) Camshaft TR106957 $327.73 9
Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.01	Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015	1) Insert, Valve In TR98063 $5.96 O/S TR98335 $30.57 O/S 2) Insert, Valve Ex TR51734 $12.96 Std. TR93910 $11.22 O/S	1) Seal, Valve TRE31617 $3.06 2) Lock, Valve TR91889 $0.51	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE60005 $17.28
1) Thermostat TRE64354 $10.66 180¢X F 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 8 4) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31 3) Fuel Filter Base with Prime TRE67225 $159.99	Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66	1) Water Pump TAR97708U $249.40 6 TRE60489 $227.48 7 TAR92641 $523.16 8 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE38087 $77.63 8 TRE50833 $104.56 8 3) Inj Grommet Kit8 TMX504 $11.61
(1): Not included in Gasket Set. Used in Saran Engines (Order separately). (2): Reusable. (3): Helicoidal Gears. (4): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (5): Kit contains TT20094 $75.08 helical gear to convert to a TRE50979, Crankshaft. (6): (m) R73604. (7): (m) R100812, (m) R127337, (m) R127918, (m) R55164. (8): Check your application for proper usage. (9): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces

Engine Desc: To 158,257 Engine Data: O'rings on Liner	Engine Dimensions: Bore: 3.86 in / 98 mm (2) Pin Ø: 1.1878 in (+/- .0001) = 30mm Block (M): T23406, T24961, T26933	Con Rod (M): RE19733 (SUB FOR AT18005) Piston (M): T23481 Farm Tractors 2020 2510	Backhoe Loaders 400 Crawler Dozers 450	Skidders 440 Forklifts 480
Engine Series: 300 Engine Model: 4.202
1) Engine O/H Kit TOK4481 $1,048.57 2) Engine I/F Kit TIK4481 $965.60 SPEC SHEET - 4.202	Piston-Liner Kit TPLK481 $173.99 Consists of: a) TT23481 $70.48 b) TAR70633 $33.05 c) TT23482 $12.50 d) TAR51902 $66.44 e) TR51112 $1.06	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TAT18030 $1,164.16 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE38558 $143.61 2)Head Gasket Set TRE38847 $96.05 3) Head Gasket TR98461 $33.99 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78 6) Exhaust Manifold Gsk TR90658 $3.09 7) Gasket Thermostat Housing TT20219 $0.75	1) Bush, Con Rod TT23471 $9.57 x4 2) Bolt, Con Rod TR74194 $2.78 x8 3 3) Bush, Bal. Shaft TR57160 $5.70 x6 6 TR91708 $11.18 x6 7 4) Bal. Shaft R/H TRE26282 $222.05 R/H 5) Bal. Shaft L/H TRE26283 $222.05 L/H 6) Camshaft TR82820 $211.09 5 7) Bal. Shaft Stop TR88112 8) Con Rod TAT18005 $87.01	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54987 5) Pump, Oil Tube TR113752 $11.93 6) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TRE33705 $10.66 180° F 4 2) Thermostat Cover TT23620 $15.12 3) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31		Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX504 $11.61 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77
(1): Do not use with Flywheel Housing (m) T20300, T22991. (3): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410. (4): Do not use with Housing (m) R54096, R70741, R74549. (5): Threaded Type. (6): TR57160, (Inner Diam 0.5 mm / 0.020 in). (7): TR91708, (Outer Diam. 2.00 mm / 0.078 in). O/S

Engine Desc: From 158,258 Engine Data: O'rings on Block	Engine Dimensions: Bore: 3.86 in / 98 mm (2) Pin Ø: 1.1878 in / (+/- .0001) = 30mm	Block (M): R53230, R53250, R55034, R72973, T32342 Con Rod (M): RE19733 (SUB FOR AT18005)	Piston (M): T23481 Farm Tractors 2020 2120 2510 Backhoe Loaders 400	Forklifts 480 Skidders 440
Engine Series: 300 Engine Model: 4.202
1) Engine O/H Kit TOK4591 $997.30 2) Engine I/F Kit TIK4591 $851.05 SPEC SHEET - 4.202 1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TAT18030 $1,164.16 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Piston-Liner Kit TAR71591 $162.02 Consists of: a) TT23481 $70.48 b) TAR70633 $33.05 c) TT23482 $12.50 d) TT32340 $60.49 e) TAR71617 $9.12 f) TR51112 $1.06 1) O/H Gasket Set TRE38558 $143.61 2)Head Gasket Set TRE38847 $96.05 3) Head Gasket TR98461 $33.99 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78 6) Exhaust Manifold Gsk TR90658 $3.09 7) Gasket Thermostat Housing TT20219 $0.75 Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4 1) Bush, Con Rod TT23471 $9.57 x4 2) Bolt, Con Rod TR74194 $2.78 x8 3 3) Bush, Bal. Shaft TR57160 $5.70 x6 6 TR91708 $11.18 x6 7 4) Bal. Shaft R/H TRE26282 $222.05 R/H 5) Bal.Shaft L/H TRE26283 $222.05 L/H 6) Camshaft TR82820 $211.09 5 7) Bal. Shaft Stop TR88112 8) Con Rod TAT18005 $87.01 1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1 1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54987 5) Pump, Oil Tube TR113752 $11.93 6) Oil Pump O'Ring TR61871 $1.57 1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 4 1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54 1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48


































1) Thermostat TRE33705 $10.66 180° F 4 2) Thermostat Cover TT23620 $15.12 3) Thermostat Cover Gsk TT20215 $0.84		1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX504 $11.61 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77













(1): Do not use with Flywheel Housing (m) T20300, T22991. (2): Always verify Bore diameter, on Block Replacement is 4.016”/102mm. (3): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410. (4): Do not use with Housing (m) R54096, R70741, R74549. (5): Threaded Type. (6): TR57160, (Inner Diam 0.5 mm / 0.020 in). (7): TR91708, (Outer Diam. 2.00 mm / 0.078 in). O/S

Engine Desc: To ESN 275,483 Engine Data: O'rings on Liner Small Pin	Engine Info: 4 Cyl Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm	Con Rod (M): T20007, R81410 Piston (M): RE53265	Farm Tractors 2520	Skidders 440A
Engine Series: 300 Engine Model: 4.219
1) Engine O/H Kit TOK4310 $1,131.71 2) Engine I/F Kit TIK4310 $975.65 SPEC SHEET - 4.219	Piston-Liner Kit TPLK310 $182.40 Consists of: a) TAR78310 $85.39 b) TAR55759 $26.30 c) TT26149 $5.47 d) TAR51903 $67.96 e) TR51112 $1.06	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT18030 $1,164.16 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE501579 $121.26 2) Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78 6) Gasket, Injection Pump TR125066 $2.62 7) Gasket, Turbo Mount TR89879 $7.48	1) Bush, Con Rod TT23471 $9.57 x4 2) Bolt, Con Rod TR74194 $2.78 x8 1 3) Bush, Bal. Shaft TR57160 $5.70 4 TR91708 $11.18 x6 6 4) Bal. Shaft R/H TRE26282 $222.05 R/H 5) Bal.Shaft L/H TRE26283 $222.05 L/H 6) Camshaft TR82820 $211.09 3 7) Bal. Shaft Stop TR88112 8) Con Rod TAT18005 $87.01	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54987 5) Pump, Oil Tube TR113752 $11.93 6) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TRE33705 $10.66 180° F 2 2) Thermostat Cover TT23620 $15.12 3) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66	1) Water Pump TAT27018 $299.99 5 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX504 $11.61 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR5193
(1): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410. (2): Do not use with Housing (m) R54096, R70741, R74549. (3): Threaded Type. (4): TR57160, (Inner Diam 0.5 mm / 0.020 in). (5): (m) R48997, (m) R51039. (6): TR91708, (Outer Diam. 2.00 mm / 0.078 in). O/S

Engine Desc: From ESN 275,484	Engine Data: O'rings on Block Large Pin Engine Info: 4 Cyl	Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm	Con Rod (M): R51727, R80034	Please see page 429 for a complete list of equipment models.
Engine Series: 300 Engine Model: 4.219 (1)
1) Engine O/H Kit TAT86984 $1,040.93 2) Engine I/F Kit TIK86984 $948.36 SPEC SHEET - 4.219	Piston-Liner Kit TAR78041 $151.32 Consists of: a) TAR77762 $77.10 b) TAR55759 $26.30 c) TR125754 $12.08 d) TR116463 $64.39 e) TAR71618 $7.95 f) TM41029 $1.07	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT18030 $1,164.16 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE501579 $121.26 2) Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78 6) Gasket, Injection Pump TR125066 $2.62 7) Gasket, Turbo Mount TR89879 $7.48	1) Bush, Con Rod TR55647 $8.00 x4 2) Bolt, Con Rod TR74194 $2.78 x8 2 3) Bush, Bal. Shaft TR57160 $5.70 x6 5 TR91708 $11.18 x6 8 4) Bal. Shaft R/H TRE26282 $222.05 R/H 5) Bal.Shaft L/H TRE26283 $222.05 L/H 6) Camshaft TR82820 $211.09 4 7) Bal. Shaft Stop TR88112 8) Con Rod TRE16495 $92.02	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54987 5) Pump, Oil Tube TR113752 $11.93 6) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TRE33705 $10.66 180° F 3 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 7 4) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66	1) Water Pump TAT27018 $299.99 6 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX504 $11.61 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77
(1): Some of these engines maybe turbocharged. (2): For Connecting Rods TRE16495 $92.02 and RE21076 Use Connecting Rod Bolt TR80033. (3): Do not use with Housing (m) R54096, R70741, R74549. (4): Threaded Type. (5): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in). (6): (m) R48997, (m) R51039. (7): Check for proper Application. (8): TR91708 $11.18 (Outer Diam. 2.00 mm / 0.078 in). O/S

Engine Info: 4 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm	Con Rod (M): R80034	Piston (M): RE30250	Please see page 430 for a complete list of equipment models.
Engine Series: 300 Engine Model: 4.239D
1) Engine O/H Kit TAT86992 $956.41 2) Engine I/F Kit TIK86992 $908.57 SPEC SHEET - 4.239D	Piston-Liner Kit TRE30250 $161.15 Consists of: a) TRE19282 $107.84 b) TRE66820 $26.88 c) TR125754 $12.08 d) TR116281 $70.79 e) TAR65507 $7.24 f) TM41029 $1.07	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT18030 $1,164.16 1 TRE20585 $1,201.08 2 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501579 $121.26 2) Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78 6) Gasket, Injection Pump TR125066 $2.62 7) Gasket, Turbo Mount TR89879 $7.48	1) Bush, Con Rod TR55647 $8.00 x4 2) Bolt, Con Rod TR80033 $3.60 x8 3 3) Bush, Bal. Shaft TR57160 $5.70 x6 5 TR91708 $11.18 x6 11 4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 10 5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 10 6) Camshaft TR82820 $211.09 4 7) Bal Shaft Stop TR88112 8) Con Rod TRE16495 $92.02 9) Cam Bearing TR119874 $11.12 9	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 8 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54987 5) Pump, Oil Tube TR113752 $11.93 8 6) Cyl Hd Cap Screw TR85363 $3.42 x18 6 7) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TRE33705 $10.66 180° F 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 8 4) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66	1) Water Pump TAR97708U $249.40 7 TAR92641 $523.16 8 TAR97717 $762.08 8 2)Water Pump Gasket TT20242 $3.83 TT20268 $4.92 Transmission Oil Pump TAL120106 $714.81 8 TAL68094 $681.20 8	Transmission Oil Pump TAL120106 $714.81 TAL68094 $681.20 1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX504 $11.61 4) Glow Plug TRE502079 $34.28 5) Cap TAT27622 $6.18 TAR85618 $8.44 6) Washer TT29539 $0.46 7) Tube 7Nut TR5193
(1): TAT18030 $1,164.16 Crankshaft 36mm (short) snout, (m) T23517. (2): TRE20585 $1,201.08 Crankshaft 60mm (long) snout, (m) R81959 or R121018. (3): For Connecting Rod (m) R58979, use TR74194 $2.78 Connecting Rod Bolt available upon request. (4): Threaded Type. (5): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in). (6): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (7): (m) R73604. (8): Check for proper application. (9): The cam bearing is used in the late style blocks and it is not included in the overhaul kit. (10): These shafts are made for bolt on weights. (11): TR91708 $11.18 (Outer Diam. 2.00 mm / 0.078 in). O/S

Engine Desc: Liter Designated Engine Info: 4 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm	Block (M): R88984 Con Rod (M): R80034 Piston (M): RE30250, RE18697	Farm Tractors 5600 Backhoe Loaders 210D 310C 310D 315C 315D 515B	Excavators 290D 70D Crawler Dozers 400G Forklifts 482C
Engine Series: 300 Engine Model: 4039D Engine
1) Engine O/H Kit TAT86992 $956.41 2) Engine I/F Kit TIK86992 $908.57 SPEC SHEET - 4039D	Piston-Liner Kit TRE30250 $161.15 Consists of: a) TRE19282 $107.84 b) TRE66820 $26.88 c) TR125754 $12.08 d) TR116281 $70.79 e) TAR65507 $7.24 f) TM41029 $1.07	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT18030 $1,164.16 13 TRE20585 $1,201.08 14 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501579 $121.26 2) Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78 3 $21.78 TR106796 $10.02 3 6) Gasket, Injection Pump TR125066 $2.62 7) Gasket, Turbo Mount TR89879 $7.48	1) Bush, Con Rod TR55647 $8.00 x4 2) Bolt, Con Rod TR80033 $3.60 x8 3) Bush, Bal. Shaft TR57160 $5.70 x6 4 TR91708 $11.18 x6 16 4) Bal. Shaft R/H TRE26282 $222.05 15 TAR69710 $320.74 5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 15 6) Camshaft TR82820 $211.09 8 $188.47 7) Camshaft Kit TRE55901 $265.90 12 8) Con Rod TRE16495 $92.02 9) Cam Bearing TR119874 $11.12	1) Pump, Oil TRE55343 $131.62 2 2) Oil Cooler TRE31929 $228.16 3) Pump, Oil Tube TR113752 $11.93 4) Cyl Hd Cap Screw TR85363 $3.42 x18 1 5) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 6 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 6 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54 6 $102.27
Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015	Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015	1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S. 2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S	1) Seal, Valve TRE31617 $3.06 2) Lock, Valve TR91889 $0.51	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE60005 $17.28
1) Thermostat TAR48675 $14.80 180° F 5 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 11 4) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $50.45 11 TRE38009 $69.25 7 TRE55390 $46.60 11 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66	1) Water Pump TAR97708U $249.40 9 TRE60489 $227.48 10 TRE16666 $728.31 11 TAR92641 $523.16 11 TAR97717 $762.08 11 2) Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE36936 $59.20 3) KIT, GROMMET TMX504 $11.61 4) Glow Plug TRE502079 $34.28
(1): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (2): May use High cap. Pump, Oil TRE65580. (3): O’ring not included in Gasket Set. Used in Saran Engines. Order separately. (4): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in) (5): Saran engines may use TRE64354. (6): Helicoidal Gears. (7): Saran Engines. (8): Threaded Type. (9): (m) R73604. (10): (m) R100812, (m) R127337, (m) R127918, (m) R55164. (11): Check application for proper usage. (12): For Late 4039 models. (13): TAT18030 $1,164.16 Crankshaft 36mm (short) snout, (m) T23517. (14): TRE20585 $1,201.08 Crankshaft 60mm (long) snout, (m) R81959 or R121018. (15): These shafts are made for bolt on weights. (16): TR91708 $11.18 (Outer Diam. 2.00 mm / 0.078 in). O/S

Engine Info: 4 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .0002) = 41mm	Con Rod (M): R80032, R113612, R122191	Piston (M): RE19278	Please see page 431 for a complete list of equipment models.
Engine Series: 300 Engine Model: 4.239T
1) Engine O/H Kit TRE54709 $1,107.22 2) Engine I/F Kit TIK54709 $1,016.74 SPEC SHEET - 4.239T	Piston-Liner Kit TRE33115 $161.15 Consists of: a) TRE19278 $107.84 b) TRE66820 $26.88 c) TR124230 $18.50 d) TR116281 $70.79 e) TAR65507 $7.24 f) TR54114 $1.84	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT18030 $1,164.16 1 TRE20585 $1,201.08 4 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501579 $121.26 2) Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78 6) Gasket, Injection Pump TR125066 $2.62 7) Gasket, Turbo Mount TR89879 $7.48	1) Bush, Con Rod TR57451 $11.38 x4 2) Bolt, Con Rod TR80033 $3.60 x8 3) Bush, Bal. Shaft TR57160 $5.70 x6 3 TR91708 $11.18 x6 11 4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 10 5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 10 6) Camshaft TR82820 $211.09 5 $188.47 7) Bal Shaft Stop TR88112 8) Con Rod TRE58347 $103.07 9) Kit, Piston Pin TRE63913 $27.07 x4 10) Cam Bearing TR119874 $11.12 9	1) Pump, Oil TRE55343 $131.62 2 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54987 5) Pump, Oil Tube TR113752 $11.93 6) Cyl Hd Cap Screw TR85363 $3.42 x18 6 7) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54

Valve, Intake TR83071 $15.56 Std. TR89223 $19.73 0.003 TR89224 $17.44 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring, Valve TR87627 $0.48
1) Thermostat TAR48675 $14.80 180° F 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 8 4) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	1) Water Pump Repair Kit See Chart 2) Turbocharger TRE26287 $695.39 8	Water Pump TAR97708U $249.40 7 TAR92641 $523.16 8 TAR97717 $762.08 8	Transmission Oil Pump TAL120106 $714.81 TAL6809 1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE3750 3) KIT, GROMMET TMX504 $11.61 4) Glow Plug TRE502079 $34.28
(1): TAT18030 $1,164.16 Crankshaft 36mm (short) snout, (m) T23517. (2): May use High cap. Pump, Oil TRE65580. (3): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in). (4): TRE20585 $1,201.08 Crankshaft 60mm (long) snout, (m) R81959 or R121018. (5): Threaded Type. (6): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (7): (m) R73604. (8): Check your application for proper usage. (9): The cam bearing is used in the late style blocks and it is not included in the overhaul kit. (10): These shafts are made for bolt on weights. (11): TR91708 $11.18 (Outer Diam. 2.00 mm / 0.078 in) O/S

Engine Desc: Liter Designated Engine Info: 4 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .0002) = 41mm	Con Rod (M): R80032, R122191, R113612 Piston (M): RE19278	Farm Tractors 5500N 5700 6200 6200L SE6200 6210 6300 6300L SE6300 6310	Backhoe Loaders 300D 310C 315C 315D 515B
Engine Series: 300 Engine Model: 4039T
1) Engine O/H Kit TRE54709 $1,107.22 2) Engine I/F Kit TIK54709 $1,016.74 SPEC SHEET - 4039T	Piston-Liner Kit TRE33115 $161.15 Consists of: a) TRE19278 $107.84 b) TRE66820 $26.88 c) TR124230 $18.50 d) TR116281 $70.79 e) TAR65507 $7.24 f) TR54114 $1.84	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT18030 $1,164.16 13 TRE20585 $1,201.08 14 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501579 $121.26 2) Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78 2 TR106796 $10.02 6) Gasket, Injection Pump TR125066 $2.62 7) Gasket, Turbo Mount TR89879 $7.48	1) Bush, Con Rod TR57451 $11.38 x4 2) Bolt, Con Rod TR80033 $3.60 x8 3) Bush, Bal. Shaft TR57160 $5.70 x6 4 TR91708 $11.18 x6 16 4) Camshaft TR82820 $211.09 8 5) Con Rod TRE58347 $103.07 6) Bal Shaft R/H TRE26282 $222.05 TAR69710 $320.74 15 7) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 15 8) Camshaft Kit TRE55901 $265.90 12 9) Kit, Piston Pin TRE63913 $27.07 x4 10) Cam Bearing TR119874 $11.12	1) Pump, Oil TRE55343 $131.62 3 2) Oil Cooler TRE31929 $228.16 11 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54987 5) Pump, Oil Tube TR113752 $11.93 6) Cyl Hd Cap Screw TR85363 $3.42 x18 1 7) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 6 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 6 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54 6










Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015	Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015	1) Insert, Valve In TR98063 $5.96 O/S TR98335 $30.57 O/S 2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S	1) Seal, Valve TRE31617 $3.06 2) Lock, Valve TR91889 $0.51	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE60005 $17.28

1) Thermostat TAR48675 $14.80 180¢X F 5 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 11 4) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE42211 $56.51 11 TRE38009 $69.25 7 TRE55390 $46.60 11 2) Fuel Pump Gasket TR27285 $1.31	1) Water Pump Repair Kit See Chart 2) Turbocharger TRE26287 $695.39 11	Water Pump TAR97708U $249.40 9 TRE60489 $227.48 10 TRE16666 $728.31 11 TRE41157 $228.62 11 TAR92641 $523.16 11 TAR97717 $762.08 11	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE38087 $77.63 3) KIT, GROMMET TMX504 $11.61 4) Glow Plug TRE502079 $34.28
(1): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (2): Saran engines, O’ring not included in Gasket Set. Order separately. (3): May use High cap. Pump, Oil TRE65580. (4): TR57160 $5.70 (Inner Diam 0.5 mm / 0.020 in). (5): Saran engines may use TRE64354. (6): Helicoidal Gears. (7): Saran Engines. (8): Threaded Type. (9): (m) R73604. (10): (m) R100812, (m) R127337, (m) R127918, (m) R55164. (11): Check application for proper usage. (12): For Late 4039 models. (13): TAT18030 $1,164.16 Crankshaft 36mm (short) snout, (m) T23517. (14): TRE20585 $1,201.08 Crankshaft 60mm (long) snout, (m) R81959 or R121018. (15): These shafts are made for bolt on weights.

Engine Desc: Small Pin Engine Info: 4 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.375 in / 35 mm	Con Rod (M): R54617	Farm Tractors 2630 2640	Backhoe Loaders 410C
Engine Series: 300 Engine Model: 4.276D
1) Engine O/H Kit TAT86990 $1,041.36 2) Engine I/F Kit TIK86990 $963.44 SPEC SHEET - 4.276D	Piston-Liner Kit TRE19831 $191.10 Consists of: a) TAR63342 $113.25 b) TRE66820 $26.88 c) TR125754 $12.08 d) TR80500 $63.25 e) TAR65507 $7.24 f) TM41029 $1.07	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TRE56792 $1,260.57 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) TR28811 $67.53 (129T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501568 $135.66 2)Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78	1) Bush, Con Rod TR57450 $19.68 x4 2) Bolt, Con Rod TR74195 $4.74 x8 4 3) Bush, Bal. Shaft TR57160 $5.70 x6 TR91708 $11.18 x6 8 4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 7 $170.32 5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 7 $151.19 Camshaft TR82820 $211.09 2	1) Pump, Oil TRE65580 $202.70 1 2) Rocker Arm TRE3197 3) Rocker Shaft TR5498 4) Cyl Hd Cap Screw TR85363 $3.42 x18 5 3	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48
1) Thermostat TAR48675 $14.80 180° F 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 5 4) Thermostat Cover Gsk TT20215 $0.84		1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 6 \| With Impeller TRE62658 $75.66 6 Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE37503 $59.20 3) KIT, GROMMET TMX504 $11.61
(1): This engine may use standard flow Pump, Oil TRE55343. (2): Threaded Type. (3): From ESN 137128 Replace all R78558 Cap Screws withFlanged Head Cap Screw TR85363. (4): When used on connecting rods marked R54617, torque bolts to 95 ft.lbs. Only. (5): Check for proper application. (6): See the Water Pump Identification Chart to make sure these part numbers are correct. You will need the water pump casting number and will need to know if you have a stamped steel pulley or a cast iron pulley. (7): These shafts are made for bolt on weights. (8): O/S

Engine Desc: Large Pin Engine Info: 4 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.625 in / 41 mm	Wheel Loaders 344E Backhoe Loaders 410C 410D 510B	Crawler Dozers 450E 450G 455E 455G	Excavators 490D 493D Skidders 340D 440C
Engine Series: 300 Engine Model: 4.276D
1) Engine O/H Kit TRE63694 $1,102.84 2) Engine I/F Kit TIK63694 $937.09 SPEC SHEET - 4.276D	Piston-Liner Kit TRE28966 $176.91 Consists of: a) TRE28919 $88.28 b) TRE66820 $26.88 c) TR124230 $18.50 d) TR80500 $63.25 e) TAR65507 $7.24 f) TR54114 $1.84	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TRE56792 $1,260.57 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) TR28811 $67.53 (129T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501568 $135.66 2) Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78	1) Bush, Con Rod TR57451 $11.38 x4 2) Bolt, Con Rod TR74195 $4.74 x8 4 3) Bush, Bal. Shaft TR57160 $5.70 x6 TR91708 $11.18 6 $11.18 x6 4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 5 $170.32 5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 5 $151.19 6) Camshaft TR82820 $211.09 2 7) Kit, Piston Pin TRE63913 $27.07 x4 8) Con Rod TRE53716 $190.66	1) Pump, Oil TRE65580 $202.70 1 2) Rocker Arm TRE31973 $34.00 3) Rocker Shaft TR5498 4) Cyl Hd Cap Screw TR85363 $3.42 x18 3	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing 3TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 2) Insert, Valve Ex TR51734 $12.96 Std. TR93910 $11.22	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48
1) Thermostat TAR48675 $14.80 180° F 2) Thermostat Cover TT23620 $15.12 3) Thermostat Cover Gsk TT20215 $0.84		1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19507 $60.74 With Impeller TRE62658 $75.66 Water Pump Gasket TT20242 $3.83 TT20268 $4.92	1) Seal, Injector TR60746 $0.38 TR48000 $1.062)Injector, Pencil TRE37503 $59.20 3) KIT, GROMMET TMX504 $11.61
1): This engine may use standard flow Pump, Oil TRE55343. (2): Threaded Type. (3): From ESN 137128 Replace all R78558 Cap Screws withFlanged Head Cap Screw TR85363. (4): When used on connecting rods marked R56187, torque bolts to 95 ft.lbs. Only. (5): These shafts are made for bolt on weights. (6): O/S

Engine Desc: Liter Designated	Engine Info: 4 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.625 in / 41 mm		Please see page 432 for a complete list of equipment models.
Engine Series: 300 Engine Model: 4045D
1) Engine O/H Kit TRE63694 $1,102.84 2) Engine I/F Kit TIK63694 $937.09	Piston-Liner Kit TRE28966 $176.91 Consists of: a) TRE28919 $88.28 b) TRE66820 $26.88 c) TR124230 $18.50 d) TR80500 $63.25 e) TAR65507 $7.24 f) TR54114 $1.84	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TRE56792 $1,260.57 10 TRE54883 $2,004.54 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) TR28811 $67.53 (129T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501568 $135.66 2)Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78	1) Bush, Con Rod TR57451 $11.38 x4 7 2) Bolt, Con Rod TR74195 $4.74 x8 7 3) Bush, Bal. Shaft TR57160 $5.70 x6 TR91708 $11.18 x6 13 4) Camshaft TR82820 $211.09 4 5) Bal Shaft R/H TRE26282 $222.05 TAR69710 $320.74 12 6) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 12 7) Kit, Piston Pin TRE63913 $27.07 x4 8) Con Rod TRE53716 $190.66 9) Camshaft Kit TRE55901 $237.42 11	1) Pump, Oil TRE65580 $202.70 1 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Rocker Shaft TR54987 5) Cyl Hd Cap Screw TR85363 $3.42 x18	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54
Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015	Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015	1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S 2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S	1) Seal, Valve TRE31617 $3.06 2) Lock, Valve TR91889 $0.51	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE60005 $17.28
1) Thermostat TAR48675 $14.80 180° F 2 2) Thermostat Cover TT23620 $15.12 3) Thermostat Cover Gsk TT20215 $0.84	1) Fuel Transfer Pump TRE4221 TRE38009 $69.25 3 2) Fuel Pump Gasket TR27285 $1.31 3) Fuel Filter Base with Primer TRE67225 $159.99	Water Pump Repair Kit See Chart	Water Pump TAR97708U $249.40 8 TRE60489 $227.48 9 TRE16666 $728.31 10	Water Pump TRE4157 1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE38087 $77.63 3) KIT, GROMMET TMX504 $11.61 4) Glow Plug TRE502079 $34.28
1): Saran engines use TRE55343 $131.62 Standard flow. (2): Saran engines may use TRE64354. (3): Saran Engines. (4): Threaded Type.(5) Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (5): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (6): Always verify Oil Cooler Type. (7): When used on connecting rods marked R56187, torque bolts to 95 ft.lbs. (8): (m) R73604. (9): (m) R100812, (m) R127337, (m) R127918, (m) R55164. (10): Crankshaft (m) R54501. This Engines model may also use crankshaft TRE54883 $2,004.54 60mm Snout; (m) R90825, R120009. PLEASE VERIFY. (11): For Late 4039 models. (12): These shafts are made for bolt on weights. (13): O/S

Engine Info: 4 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.625 in / 41 mm		Please see page 433 for a complete list of equipment models.
Engine Series: 300 Engine Model: 4.276T
1) Engine O/H Kit TRE61612 $1,102.84 2) Engine I/F Kit TIK61612 $1,023.18 SPEC SHEET - 4.276T	Piston-Liner Kit TRE53073 $183.95 Consists of: a) TRE48469 $92.70 b) TRE66820 $26.88 c) TR124230 $18.50 d) TR80500 $63.25 e) TAR65507 $7.24 f) TR54114 $1.84	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 4	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TAR97517 $13.44 Std. TAR97653 $13.44 0.010 TAR97654 $13.44 0.020 TAR97655 $15.05 0.030 Use 4
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TRE56792 $1,260.57 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) TR28811 $67.53 (129T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501568 $135.66 2) Head Gasket Set TRE38851 $70.33 3) Head Gasket TR125863 $39.74 4) Oil Pan Gasket TR97342 $14.21 5) Rocker Cover Gsk TR73521 $21.78 TR106796 $10.02 7	1) Bush, Con Rod TR57451 $11.38 x4 5 2) Bolt, Con Rod TR74195 $4.74 x8 3) Bush, Bal. Shaft TR57160 $5.70 x6 TR91708 $11.18 X6 9 4) Bal. Shaft R/H TRE26282 $222.05 TAR69710 $320.74 8 5) Bal Shaft L/H TRE26283 $222.05 TAR69711 $261.54 8 6) Camshaft TR82820 $211.09 3 7) Kit, Piston Pin TRE63913 $27.07 x4 8) Con Rod TRE53716 $190.66	1) Pump, Oil TRE65580 $202.70 1 2) Rocker Arm TRE31973 $34.00 3) Rocker Shaft TR54987 4) Cyl Hd Cap Screw TR85363 $3.42 x18 4 5) Tensioner Belt TAL110621 $99.41	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x8 6) Cam. Gear TT20070 $114.54


Valve, Intake TR83071 $15.56 Std. TR89223 $19.73 0.003 TR89224 $17.44 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48
1) Thermostat TAR48675 $14.80 180° F 2) Thermostat Cover TT23620 $15.12 3) Water Temp Sensor TRE51774 $27.68 6 4) Thermostat Cover Gsk TT20215 $0.84		1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	1) Water Pump Repair Kit Without Impeller TRE19510 $69.50 With Impeller TRE11348 $101.78 2)Turbocharger TRE26287 $695.39 6	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE3750 3) KIT, GROMMET TMX504 $11.61
(1): This engine may use Standard Flow Pump, Oil TRE55343. (2): Do not use 45 degree Valves with RE56545 Head. (3): Threaded Type (4): From ESN 137128 Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363 $3.42 (5): When used on connecting rods marked R56187, torque bolts to 95 ft.lbs. Only. (6): Check for proper application (7): Saran engines, O’ring not included in Gasket Set. Order separately. (8): These shafts are made for bolt on weights. (9): O/S


Engine Desc: To ESN 158,975 Engine Data: O'rings on Liner	Engine Dimensions: Bore: 3.86 in / 98 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm	Block (M): T24967, T24968	Con Rod (M): T20007, R81410	Piston (M): T23481 Wheel Loaders 544
Engine Series: 300 Engine Model: 6.303
1) Engine O/H Kit TOK6481 $1,526.66 2) Engine I/F Kit TIK6481 $1,415.29 SPEC SHEET - 6.303	Piston-Liner Kit TPLK481 $173.99 Consists of: a) TT23481 $70.48 b) TAR70633 $33.05 c) TT23482 $12.50 d) TAR51902 $66.44 e) TR51112 $1.06	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 6	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 6
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TAT22562 $2,118.73 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE38568 $257.07 2)Head Gasket Set TRE38571 $179.15 3) Head Gasket TR98462 $76.50 4) Oil Pan Gasket TR97344 $30.51 5) Rocker Cover Gsk TR75728 $24.84	1) Bush, Con Rod TT23471 $9.57 x6 2) Bolt, Con Rod TR74194 $2.78 x12 2 3) Camshaft TR82821 $377.62 3 4) Con Rod TAT18005 $87.01	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Pump, Oil Tube TR113752 $11.93 5) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x12 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48
Thermostats TAR70601 180° F 4 TAR77411 $139.39 1195ºF 4		1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19510 $69.50 With Impeller TMX132 $84.43	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX506 $17.41 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77
(1): Do not use with flywheel housing (m) T20300,T22991. (2): Use TR74194 $2.78 with C.Rod (m) T20007; use TR80033 $3.60 with C.Rod (m) R81410. (3): Threaded Type. (4): Verify JD parts manual.

PistEngine Desc: From ESN 158,976 Engine Data: O'rings on Block	Engine Dimensions: Bore: 3.86 in / 98 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm	Block (M): R53260, R55035, R55351, R72970, R79280, T32346	Con Rod (M): T20007, R81410 on (M): T23481	Farm Tractors 3420 Skidders 540 Wheel Loaders 544
Engine Series: 300 Engine Model: 6.303
1) Engine O/H Kit TOK6591 $1,498.75 2) Engine I/F Kit TIK6591 $1,262.76 SPEC SHEET - 6.303	Piston-Liner Kit TAR71591 $162.02 Consists of: a) TT23481 $70.48 b) TAR70633 $33.05 c) TT23482 $12.50 d) TT32340 $60.49 e) TAR71617 $9.12 f) TR51112 $1.06	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 6	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 6
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TAT22562 $2,118.73 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE38568 $257.07 2)Head Gasket Set TRE38571 $179.15 3) Head Gasket TR98462 $76.50 4) Oil Pan Gasket TR97344 $30.51 5) Rocker Cover Gsk TR75728 $24.84	1) Bush, Con Rod TT23471 $9.57 x6 2) Bolt, Con Rod TR74194 $2.78 x12 2 3) Camshaft TR82821 $377.62 3 4) Con Rod TAT18005 $87.01	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Pump, Oil Tube TR113752 $11.93 5) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x12 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48
Thermostats TAR70601 180° F 4 TAR77411 $139.39 195º F 4		1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TRE19510 $69.50 With Impeller TMX132 $84.43	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX506 $17.41 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77


(1): Do not use with flywheel housing (m) T20300,T22991. (2): Use TR74194 $2.78 with C.Rod (m) T20007; use TR80033 $3.60 with C.Rod (m) R81410. (3): Threaded Type. (4): Verify JD parts manual.

Engine Desc: To ESN 277,548 Engine Data: O'rings on Liner Small Pin	Engine Info: 6 Cyl, Block (m) T24968	Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm	Con Rod (M): T20007, R81410 Piston (M): RE53265, T30015, R51451, AR78310	Farm Tractors 3120 Skidders 540A Cotton Pickers 699
Engine Series: 300 Engine Model: 6.329
1) Engine O/H Kit TOK6310 $1,614.63 2) Engine I/F Kit TIK6310 $1,050.54 SPEC SHEET - 6.329	Piston-Liner Kit TPLK310 $182.40 Consists of: a) TAR78310 $85.39 b) TAR55759 $26.30 c) TT26149 $5.47 d) TAR51903 $67.96 e) TR51112 $1.06	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 6	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 6
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT22562 $2,118.73 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02	1) O/H Gasket Set TRE501580 $175.86 2) Head Gasket Set TRE38852 $106.33 3) Head Gasket TR114157 $38.37 4) Oil Pan Gasket TR97344 $30.51 5) Rocker Cover Gsk TR75728 $24.84 6) Gasket, Turbo Mount TR89879 $7.48 7) Gasket Thermostat Housing TT20219 $0.75	1) Bush, Con Rod TT23471 $9.57 x6 2) Bolt, Con Rod TR74194 $2.78 x12 1 3) Camshaft TR82821 $377.62 2 4) Con Rod TAT18005 $87.01	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Pump, Oil Tube TR113752 $11.93 5) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x12 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48
Thermostats TAR70601 180° F 3 TAR77411 $139.39 195º F 3		1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TMX9398 $97.32 With Impeller TMX131 $121.68	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX506 $17.41 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77
(1): Use TR74194 $2.78 with C.Rod (m) T20007; use TR80033 $3.60 with C.Rod (m) R81410. (2): Threaded Type. (3): Verify JD parts manual.

Engine Desc: To ESN 277,549 Engine Data: O'rings on Block Small Pin	Engine Info: 6 Cyl Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.1878 in / (+/- .0001) = 30mm	Con Rod (M): T20007, R81410 Piston (M): RE53265, T30015, AR78310	Cotton Pickers 499 699 Farm Tractors 3120 4030 4420	Wheel Loaders 544A Motor Graders 570A Skidders 540A
Engine Series: 300 Engine Model: 6.329
1) Engine O/H Kit TOK6593 $1,447.16 2) Engine I/F Kit TIK6593 $1,249.86 SPEC SHEET - 6.329	Piston-Liner Kit TAR71593 $163.43 Consists of: a) TAR78310 $85.39 b) TAR55759 $26.30 c) TT26149 $5.47 d) TR116463 $64.39 e) TAR71618 $7.95 f) TR51112 $1.06	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 6	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 6
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT22562 $2,118.73 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE501580 $175.86 2) Head Gasket Set TRE38852 $106.33 3) Head Gasket TR114157 $38.37 4) Oil Pan Gasket TR97344 $30.51 1 5) Rocker Cover Gsk TR75728 $24.84 6) Gasket, Turbo Mount TR89879 $7.48 7) Gasket Thermostat Housing TT20219 $0.75	1) Bush, Con Rod TT23471 $9.57 x6 2) Bolt, Con Rod TR74194 $2.78 x12 2 3) Camshaft TR82821 $377.62 3 4) Con Rod TAT18005 $87.01	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Pump, Oil Tube TR113752 $11.93 5) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x12 6) Cam. Gear TT20070 $114.54
Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48
Thermostats TAR70601 180° F 4 TAR77411 $139.39 195º F 4		1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TMX9398 $97.32 With Impeller TMX131 $121.68	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX506 $17.41 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77
(1): For Tractor Model 4030 order TR97345. (2): Use TR74194 $2.78 with C.Rod (m) T20007; use TR80033 $3.60 with C.Rod (m) R81410. (3): Threaded Type. (4): Verify JD parts manual.

Engine Desc: From ESN 277,549 Engine Data: O'rings on Block Large Pin Engine Info: 6 Cyl	Engine Dimensions: Bore: 4.02 in / 102 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm Con Rod (M): RE16495	Piston (M): AR77762 Cotton Pickers 499 Combines 950 960 4400	Farm Tractors 2840 3130 3530 4030 4425 Wheel Loaders 444 444C 444D 444CH 544A	Motor Graders 570A Backhoe Loaders 710B
Engine Series: 300 Engine Model: 6.329
1) Engine O/H Kit TAT86986 $1,415.29 2) Engine I/F Kit TIK86986 $1,352.92 SPEC SHEET - 6.329	Piston-Liner Kit TAR78041 $151.32 Consists of: a) TAR77762 $77.10 b) TAR55759 $26.30 c) TR125754 $12.08 d) TR116463 $64.39 e) TAR71618 $7.95 f) TM41029 $1.07	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 6	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 6
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT22562 $2,118.73 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR114282 $39.11 (142T)	1) O/H Gasket Set TRE501580 $175.86 2) Head Gasket Set TRE38852 $106.33 3) Head Gasket TR114157 $38.37 4) Oil Pan Gasket TR97344 $30.51 1 5) Rocker Cover Gsk TR75728 $24.84 6) Gasket, Turbo Mount TR89879 $7.48 7) Gasket Thermostat Housing TT20219 $0.75	1) Bush, Con Rod TR55647 $8.00 x6 2) Bolt, Con Rod TR74194 $2.78 x12 3) Camshaft TR82821 $377.62 2 4) Con Rod TRE16495 $92.02 3	1) Pump, Oil TRE55343 $131.62 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Pump, Oil Tube TR113752 $11.93 5) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x12 6) Cam. Gear TT20070 $114.54

Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48
1) Thermostats TAR70601 180° F 5 TAR77411 $139.39 195ºF 5 TRE33705 $10.66 180ºF 5 2) Water Temp Sensor TRE51774 $27.68 4		1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit Without Impeller TMX9398 $97.32 With Impeller TMX131 $121.68	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX506 $17.41 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77
(1): For Tractor Model 4030 order TR97345. (2): Threaded Type. (3): For Connecting Rods RE16495 and RE21076 Use Connecting Rod Bolt TR80033. (4): Check for proper application. (5): Verify JD parts manual.

Engine Info: 6 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.3750 in / (+/- .0002) = 35mm	Con Rod (M): R80034	Piston (M): RE30250	Please see page 435 for a complete list of equipment models.
Engine Series: 300 Engine Model: 6.359D
1) Engine O/H Kit TRE50784 $1,383.91 2) Engine I/F Kit TIK50784 $1,247.90 SPEC SHEET - 6059D, 6.359D	Piston-Liner Kit TRE30250 $161.15 Consists of: a) TRE19282 $107.84 b) TRE66820 $26.88 c) TR125754 $12.08 d) TR116281 $70.79 e) TAR65507 $7.24 f) TM41029 $1.07	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 6	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 6
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 1 3) Crankshaft TAT22562 $2,118.73 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR28811 $67.53 (129T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501580 $175.86 2) Head Gasket Set TRE38852 $106.33 3) Head Gasket TR114157 $38.37 4) Oil Pan Gasket TR97344 $30.51 5) Rocker Cover Gsk TR75728 $24.84 6) Gasket, Turbo Mount TR89879 $7.48 7) Gasket Thermostat Housing TT20219 $0.75	1) Bush, Con Rod TR55647 $8.00 x6 2) Bolt, Con Rod TR80033 $3.60 x12 3) Camshaft TR82821 $377.62 3 4) Con Rod TRE16495 $92.02	1) Pump, Oil TRE55343 $131.62 2 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 4) Pump, Oil Tube TR113752 $11.93 5) Cyl Hd Cap Screw TR85363 $3.42 x26 4 6) Oil Pump O'Ring TR61871 $1.57	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 x12 6) Cam. Gear TT20070 $114.54





Valve, Intake TR79623 $9.82 Std. TR79628 $9.82 0.003 TR79629 $9.83 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 TR79626 $13.01 0.015	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48



1) Thermostat TAR48675 $14.80 180° F 1 2) Water Temp Sensor TRE51774 $27.68 6	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit See Chart	Water Pump TRE31600 $451.79 5 TRE97717 6 Transmission Oil Pump TAL120106 $714.81 TAL68094 $681.20	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TAR89564 $59.20 3) Kit, Grommet TMX506 $17.41 4) Cap TAT27622 $6.18 TAR85618 $8.44 5) Washer TT29539 $0.46 6) Tube Nut TR51937 $5.77





(1): Saran engines may use TRE64354. (2): Some Engines Models may use High Capacity Pump, Oil TRE65580. (3): Threaded Type. (4): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (5): Check serial number for proper application. (6): Check for proper application.

Engine Info: 6 Cyl	Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .000 2) = 41mm	Con Rod (M): R80032, R113612 Piston (M): RE22678, RE19278	Combines 9400 Cotton Pickers 7445 7484 9930 Farm Tractors 3140C 3540 3550 4050 7200	Backhoe Loaders 710B 710C Wheel Loaders 444D 544E 544EH 544G
Engine Series: 300 Engine Model: 6.359T
1) Engine O/H Kit TRE50783 $1,431.08 2) Engine I/F Kit TIK50783 $1,358.36 SPEC SHEET - 6059T, 6.359T	Piston-Liner Kit TRE33115 $161.15 Consists of: a) TRE19278 $107.84 b) TRE66820 $26.88 c) TR124230 $18.50 d) TR116281 $70.79 e) TAR65507 $7.24 f) TR54114 $1.84	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 6	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 6
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT22562 $2,118.73 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR28811 $67.53 (129T) TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501580 $175.86 2) Head Gasket Set TRE38852 $106.33 3) Head Gasket TR114157 $38.37 4) Oil Pan Gasket TR97344 $30.51 5) Rocker Cover Gsk TR75728 $24.84 6) Gasket, Turbo Mount TR89879 $7.48 7) Gasket Thermostat Housing TT20219 $0.75	1) Bush, Con Rod TR57451 $11.38 x6 2) Bolt, Con Rod TR80033 $3.60 x12 3) Camshaft TR82821 $377.62 6 4) Con Rod TRE58347 $103.07 5) Kit, Piston Pin TRE63913 $27.07 x6	1) Pump, Oil TRE65580 $202.70 3 2) Oil Cooler TRE31929 $228.16 3) Rocker Arm TRE31973 $34.00 5 4) Pump, Oil Tube TR113752 $11.93 5) Cyl Hd Cap Screw TR85363 $3.42 X26 1	1) Lower Gear TAT24252 $117.41 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x12 6) Cam. Gear TT20070 $114.54
Valve, Intake TR83071 $15.56 Std. TR89223 $19.73 0.003 TR89224 $17.44 0.015	Valve, Exhaust TR79624 $12.11 Std. TR79625 $11.46 0.003 4 TR79626 $13.01 0.015 4	1) Insert, Valve In TR73064 $12.02 Std. 2) Insert, Valve Ex TR51734 $12.96 Std.	1) Cap, Valve TT20129 $2.77 2) Lock, Valve TT20077 $0.97	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE11410 $12.79 3) O'ring Valve TR87627 $0.48
1) Thermostat TAR48675 $14.80 180° F 2 2) Water Temp Sensor TRE51774 $27.68 7 3) Water Temp Sensor TRE52722 $16.59 7	1) Fuel Transfer Pump TRE42211 $56.51 2) Fuel Pump Gasket TR27285 $1.31	Water Pump Repair Kit See Chart Water Pump TAR97717 $762.08 7	Transmission Oil Pump TAL120106 $714.81	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE37503 $59.20 3) KIT, GROMMET TMX506 $17.41



(1): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (2): Saran engines may use TRE64354. (3): Some Engines Models may use Standard Capacity Pump, Oil TRE55343. (4): Do not use 45 Degrees Valves with RE56545 Head. (5): To ESN 379968. (6): Threaded Type. (7): Check for proper application.

Engine Info: 6 Cyl Engine Dimensions: Bore: 4.19 in / 106.5 mm Pin Ø: 1.6250 in / (+/- .0002) = 41mm	Con Rod (M): R80032 Engine Desc: Liter Designated Piston (M): RE22678	Farm Tractors 3140C 6600 7200 Cotton Pickers 7445 7484 9930	Combines 9400 Wheel Loaders 444D 544E 544EH 544G Backhoe Loaders 710B 710C	Motor Grader 570B Skidder 540E 540G 548E 548G
Engine Series: 300 Engine Model: 6059T
1) Engine O/H Kit TRE50783 $1,431.08 2) Engine I/F Kit TIK50783 $1,358.36 SPEC SHEET - 6059T, 6.359T	Piston-Liner Kit TRE33115 $161.15 Consists of: a) TRE19278 $107.84 b) TRE66820 $26.88 c) TR124230 $18.50 d) TR116281 $70.79 e) TAR65507 $7.24 f) TR54114 $1.84	Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 6	Thrust Bearing TAT21139 $31.78 Std. TAT21132 $35.60 0.010 TAT21134 $31.78 0.020 TAT21136 $35.60 0.030 Use 1	Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030 Use 6
1) Front Seal TAR67942 $8.22 2) Rear Seal TRE44574 $30.44 3) Crankshaft TAT22562 $2,118.73 4) Crankshaft, Gear TT20094 $75.08 5) Ring Gear TR28811 $67.53 (129T) TR114282 $39.11 (142T) 6) Sleeve, Front TR81989 $33.02 7) Packing, Sleeve TH35244 $0.13	1) O/H Gasket Set TRE501580 $175.86 2) Head Gasket Set TRE38852 $106.33 3) Head Gasket TR114157 $38.37 4) Oil Pan Gasket TR97344 $30.51 5) Rocker Cover Gsk TR75728 $24.84 6) Gasket, Turbo Mount TR89879 $7.48 7) Gasket Thermostat Housing TT20219 $0.75	1) Bush, Con Rod TR57451 $11.38 x6 2) Bolt, Con Rod TR80033 $3.60 x12 3) Camshaft TR82821 $377.62 6 4) Con Rod TRE58347 $103.07 5) Kit, Piston Pin TRE63913 $27.07 x6	1) Pump, Oil TRE65580 $202.70 3 2) Oil Cooler TRE31929 $228.16 3) Pump, Oil Tube TR113752 $11.93 4) Cyl Hd Cap Screw TR85363 $3.42 x26 1	1) Lower Gear TAT24252 $117.41 4 2) Lower Bushing TT26321 $7.66 3) Upper Gear TAT18009 $147.74 4 4) Upper Bushing TT20034 $5.89 5) Cam. Follower TT20073 $11.56 x12 6) Cam. Gear TT20070 $114.54 4
Valve, Intake TR98062 $14.59 Std. TR97490 $14.89 0.015	Valve, Exhaust TR90692 $17.26 Std. TR97492 $19.42 0.015	1) Insert, Valve In TR98063 $5.96 Std. TR98335 $30.57 O/S 2) Insert, Valve Ex TR85687 $8.82 Std. TR93910 $11.22 O/S	1) Seal, Valve TRE31617 $3.06 2) Lock, Valve TR91889 $0.51	1) Spring, Valve TR26125 $2.91 2) Rotator, Valve TRE60005 $17.28
1) Fuel Transfer Pump TRE42211 $56.51 TRE38009 $69.25 5 2) Thermostat TAR48675 $14.80 180° F 2 3) Water Temp Sensor TRE51774 $27.68 8 4) Water Temp Sensor TRE52722 8	Water Pump Repair Kit See Chart	Water Pump TAR97708U $249.40 7 TRE16666 $728.31 8 TRE41157 $228.62 TAR92641 $523.16 8 TAR97717 $762.08 8	Transmission Oil Pump TAL120106 $714.81 8	1) Seal, Injector TR60746 $0.38 TR48000 $1.06 2) Injector, Pencil TRE38087 $77.63 3) KIT, GROMMET TMX506 $17.41 4) Glow Plug TRE502079 $34.28
(1): Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363. (2): Saran engines may use TRE64534. (3): Some Engine Models may use Standard Capacity Pump, Oil TRE55343. (4): Helicoidal Gears. (5): Saran Engines. (6): Threaded Type. (7): (m) R73604. (8): Check for proper application.
